The amplifier offers straight 1 V and 70 V line inputs, and 25 and 70 V and 4 Ω outputs. It can extend the power of the PLE- series mixer-amplifier or be combined with the PLE-10M2 mixer, or work anywhere where more power on an existing 70 V line is needed, or when a line level signal is provided.

If you own a Bosch 70-volt amplifiers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

Features

• 120 watts, 100 volt line
• Very high audio performance power amps
• Can be used to boost Plena Voice alarm systems with system monitoring
• XLR input and XLR loop through output
• 100 volt line input (euro connector), ideal for remote location booster amps
• 100v, 70v and 8 ohm outputs
• Headphone monitoring socket
• Temperature controlled fan
• AC and 24VDC operation
• Built-in battery charger
• LED VU Meter
• 19" rack mount brackets

Specifications

• Output power: 120 watts
• Impedance: 100v, 70v and 8 ohm outputs
• No. Inputs: XLR input
• Output zones: 1 zone
• Rack mountable: Included
• Power supply: 230VAC & 24VDC
• Dimensions (HxWxD): 100mm x 430mm x 270mm
• ‘U’ height: 2U
• Weight: 10.5Kg
