Features

• Affordable A/B selector with 1-click operation and silent switching
• 2-way selector for using A/B input with one output, or vice-versa
• Instantly change guitars, effects setups or amplifiers, or switch between an amp and tuner

Specifications

• Nominal Input Level: -20 dBu
• Nominal output Level: -20 dBu
• Control: Pedal
• Indicators: A (red), B (yellow)
• Connectors: A jack, B jack, IN/OUT jack
• Current Draw5 mA or less

  • * Expected battery life under continuous use: Carbon: 100 hours
  • * This figure will vary depending on the actual conditions of use.
• Power Supply: Dry Battery [R03/LR03 (AAA) type] x 2
• Accessories: Owner's Manual, Dry Battery [R03/LR03 (AAA) type] x 2, Number Sticker
• Width: 96 mm; 3-13/16 inches
• Depth: 90 mm; 3-9/16 inches
• Height: 43 mm; 1-3/4 inches
• Weight: 240 g; 0 lbs. 9 oz.
