Combining sophisticated BOSS tone technologies with a sleek, ultra-modern hardware design, the BOSS GX-100 delivers world-class performance wherever you go. Discover 23 AIRD amplifiers and more than 150 effects taken from the flagship GT-1000, and create incredible tones in seconds with the intuitive touch screen color display. You get virtually endless tone shaping possibilities with up to 15 simultaneous effect blocks, in combination with in-depth, real-time control via integrated footswitches, an expression pedal, and support for external control.

Features

• Powerful, easy-to-use amp/effects processor for guitar and bass
• 24-bit AD/DA, 32-bit floating-point processing, and 48 kHz sampling rate
• Authentic tube amplifier tone and touch response with AIRD technology
• 23 amplifier types and over 150 BOSS effects
• Ultra-flexible amp/effect routing with 15 assignable blocks
• Wide selection of onboard speaker types and support for loading WAV speaker IRs
• Streamlined modern design with intuitive color touch display and rugged metal chassis
• Unlimited effects control with freely assignable onboard footswitches and expression pedal with toe switch
• Connect up to two footswitches or an expression pedal for expanded control
• Send/return loop for external pedals or four-cable method
• Control jack for remote channel switching on your amplifier
• MIDI I/O jacks and multi-channel computer recording via USB
• Edit sounds from your computer with BOSS Tone Studio for macOS and Windows
• Download and share Livesets at BOSS Tone Exchange

Authentic Amps and Cabs

Thanks to AIRD technology, supported by BOSS's refined Tube Logic approach, the GX-100 delivers outstanding tone and authentic tube amp response in any scenario. AIRD is in the very DNA of every GX-100 guitar and bass amplifier, and AIRD Output Select types allow you to perfectly tweak the sound for any destination - whether it's an amplifier input, FRFR monitor, or house PA. With a vast collection of integrated speaker cabs available, and slots for importing your own speaker IRs via USB.

Exceptional Effects

Create almost any sound you can imagine with the GX-100, which features over 150 studio-grade effects from BOSS's extensive catalog. From various overdrives and distortions, to BOSS icons like Slow Gear, Octave, and beyond. There's also a versatile collection of modulation effects, delays, and reverbs, along with many other bass-centric effects. You can even connect your favorite stomps or your amplifier's effects loop to the send/return jacks for further flexibility.

Craft Your Personal Voice

Boasting 100 preset memories, the GX-100 allows you to start playing straight away, while streamlined editing lets you tweak them for your needs, or create new ones from scratch. With 15 dedicated block types, you can let your imagination run wild with two amp blocks and effects that you can chain in series or parallel to create all types of unique sounds. You get plenty of storage to cover any song or style with 200 available user memories.

Touch and Go

A vivid color touch display gives intuitive control of patch and effects selection, parameter adjustments, signal flow tweaks, and more, making sound creation and on-the-fly editing easier than ever with the GX-100. Working in harmony with the four knobs and page buttons on the panel, the display provides a pleasant experience, free of frustration, and keeping your attention on the music at hand.

Your Partner in Tone

While it is a fantastic tool for use while performing, the GX-100 doubles as a USB audio interface for capturing performances on a computer. Capture your music directly into your favorite DAW, re-amp tracks, and use the GX-100 to monitor the overall playback. Practice any time, anywhere you go, without disrupting the household or disturbing your neighbours with the Headphone output, and the integrated looper is the perfect companion for jamming, fleshing out sounds and ideas, and expanding your creative horizons while performing.

Go Deeper with BOSS Tone Studio

Tweak every parameter of the GX-100, save sounds, and organize Live Sets for different gigs from the comfort of your computer via the BOSS Tone Studio for macOS and Windows. With the optional Bluetooth Audio MIDI Dual Adapter, you can adjust settings on the wirelessly from the BOSS Tone Studio App on your mobile device, or stream music playback directly from your device.

Specifications

• Audio
  • Sampling Frequency: 48kHz
  • AD Conversion: 24-Bits + AF Method
  • DA Conversion: 24-Bits
  • Processing: 32-Bit Floating Point
• Effects
  • Effects Types: 154
  • Max. Number of Effects: 15 + 3 (DIVIDER/MIXER, SEND/RETURN, PHRASE LOOP)
• Memories
  • Preset: 100
  • User: 200
• Phrase Loop
  • Mono: 38 sec.
  • Stereo: 19 sec.
• Tuner Internal Detection: +/-0.1 Cent
• Input
  • Nominal Input Level: -10dBu
  • Max. Input Level: +18dBu
  • Input Impedance: 1MΩ
  • Return Input Level: -10dBu
  • Max. Return Level: +8dBu
  • Return Impedance: 1MΩ
• Output
  • Nominal Output Level: -10dBu
  • Output Impedance: 1kΩ
  • Recommended Load Impedance: >10kΩ
  • Nominal Phones Level: -10dBu
  • Phones Impedance: 44Ω
  • Recommended Phones Load Impedance: >44Ω
  • Nominal Send Level: -10dBu
  • Send Impedance: 1kΩ
  • Recommended Send Load Impedance: >10kΩ
• Display: Color Graphic LCD (480 x 272 Dots) Touch Screen
• Connectors
  • Input Jack: ¼" TS Phone Type
  • Output (L/MONO, R) Jacks: ¼" TS Phone Type
  • Send Jack: ¼" TS Phone Type
  • Return Jack: ¼" TS Phone Type
  • Phones Jack: Stereo ¼" Phone Type
  • CTL3, 4/EXP2 Jack: ¼" TRS Phone Type
  • AMP CTL1, 2 Jack: ¼" TRS Phone Type
  • MIDI (IN/OUT): 5-Pin DIN Connector
  • USB Computer Port: USB B-Type
  • DC IN Jack
• Power
  • Power Supply: AC Adaptor
  • Current Draw: 1.2A
• Accessories
  • AC Adaptor (PSB-1U + AC Cord Set)
  • Owner's Manual
  • Leaflet "USING THE UNIT SAFELY"
• Dimensions
  • 460mm (W) x 193mm (D) x 73mm (H)
  • 3.5kg
