Set up is quick and streamlined, eliminating the connection hassles found with other systems. Performance is rock solid, with 14-channel scanning and long transmission range.

And common AA alkaline batteries provide long-lasting operation, plus fast change-out to keep the show rolling. From singers, speakers, and beatboxers to DJs, MCs, and beyond, the WL-30XLR makes it easy for everyone to embrace premium wireless microphone sound.

---

Features

• Plug-and-play wireless system for a standard dynamic XLR microphone
• Premium audio performance with lightning-fast BOSS wireless technology
• Fast, two-step visual process for hassle-free set up
• Up to 11 hours of runtime with regular AA alkaline batteries
• Transmission range: 230 feet/70 meters (line-of-sight propagation)*
• Rock-solid wireless performance with 14-channel scanning
• Battery LED for checking available runtime
• Light and compact transmitter for comfortable handheld performance
• Receiver connects to an XLR mic input on a mixer, amplifier, audio interface, etc.
• Channel lock function for worry-free operation
• *The transmission range may vary due to local conditions.

---

Specifications

(RECEIVER)

• Wireless Format: BOSS proprietary digital audio format
• Wireless carrier frequency: 2.4 GHz
• Compatible Channels: 14 (May vary due to local conditions)
• Transmission Range: 230 feet line-of-sight (May vary due to local conditions)
• Latency: 2.3 ms
• Dynamic Range: 110 dB or greater
• Frequency Response: 20 Hz--20 kHz
• Nominal Output Level: -40 dBu
• Non Clip Maximum Output level (1 kHz, typ.): 0 dBu
• Output Impedance: 600 ohm
• Recommended Load Impedance: 10 k ohms or greater
• Controls: POWER button; CH button; SCAN button
• Display: 7 segments, 2 characters (LED)
• Indicators: POWER; RECEIVE
• Connectors: Output plug: XLR type
• Power Supply: Alkaline battery (AA, LR6) x 1
• Current Draw: 130 mA
• Expected battery life under continuous use: Alkaline battery (AA, LR6): Approximately 11 hours * These figures will vary depending on the actual conditions of use.
• Accessories: Owner's Manual; Leaflet USING THE UNIT SAFELY; Transmitter; Alkaline battery (AA, LR6) x 1
• Width: 23 mm; 15/16 inches
• Depth: 27 mm; 1-1/16 inches
• Height: 99 mm; 3-15/16 inches
• Weight (including battery): 90 g; 3 oz

TRANSMITTER (WL-30XLRT)

• Nominal Output Level: -40 dBu (4 k ohms)
• Non Clip Maximum Output level (1 kHz, typ.): 0 dBu
• Controls: POWER button; CH button
• Display: 7 segments, 2 characters (LED)
• Indicators: POWER
• Connectors: Input plug: XLR type
• Power Supply: Alkaline battery (AA, LR6) x 1
• Current Draw: 120 mA
• Expected battery life under continuous use: Alkaline battery (AA, LR6): Approximately 14 hours. * These figures will vary depending on the actual conditions of use.
• Width: 23 mm; 15/16 inches
• Depth: 27 mm; 1-1/16 inches
• Height: 99 mm; 3-15/16 inches
• Weight: 90 g; 3 oz

---

Watch: BOSS WL-30XLR - Wireless System for microphone
