Specifications

• NO OF STRINGS: 6
• ORIENTATION: Right Handed
• HEADSTOCK: Straight Heritage Headstock
• TUNERS: Chapman Classic Closed (18:1 Gearing)
• STRING NUT: 42mm Graph Tech Black TUSQ XL Nut
• NECK: Maple with Satin Finish
• NECK JOINT: Recessed Bolt-on Neck
• NECK SIZE WIDTH: NUT 42mm 24F 57mm • THICKNESS: 1F 23.5mm 12F 25mm PROFILE: C Shape
• TRUSS ROD: Dual Action
• FRETBOARD: Macassar Ebony Fretboard with Rolled Edges
• FRETBOARD RADIUS: 350mm
• FRETS: 24 Jumbo Nickel Frets
• FRET MARKERS: Pearl Side Dots and Pearl Front Dot Inlays
• 12TH FRET INLAY: Pearl Infinity
• SCALE LENGTH: 711mm (~28")
• BODY TOP: Poplar Burl Veneer On Flat Top with Gloss Finish
• BODY BACK: Mahogany with Gloss Finish
• BODY BINDING: Reveal
• BODY CARVES: Arm Carve, Front Lower Spoon Cut, Rear Tummy Cut, Rear Lower Spoon Cut, Rear Heel Contour
• BRIDGE: Chapman String-Through Hardtail
• NECK PICKUP: Seymour Duncan Sentient Humbucker
• MAGNET: Alnico 5
• OUTPUT: 7.8k ohms
• BRIDGE PICKUP: Seymour Duncan Pegasus Humbucker
• MAGNET: Alnico 5 OUTPUT: 12.5k ohms
• PICKUP SWITCH: 3 Way Blade Switch with Coil Split on Push-Pull Tone Knob
• CONTROLS: Master Volume (500k), Master Tone with Push-Pull (500k)
• STRAP BUTTONS: Chapman Classic Strap Buttons
• STRINGS: Ernie Ball Regular Slinky Nickel Wound, 10-46
• GUITAR WEIGHT: Approx. 3.5kg (7.7lbs)
• PICKUP SWITCHING: TONE KNOB IN; TONE KNOB OUT

  • POSITION 1 Bridge; Bridge Coil Split (Outer Coil)
  • POSITION 2 Bridge + Neck; Bridge + Neck Both Split (Outer Coils)
  • POSITION 3 Neck; Neck Coil Split (Outer Coil)
