Features

SEMI-HOLLOW CONSTRUCTION The Joe Walsh Alliance Series features an unusual extra slim semi-hollow construction. Besides the unique semi-hollow tone, this makes the guitar handle more like a thin solid-body. PICKUPS The LittleToaster mini-humbucker and SingleTwin Mini noiseless singlecoil deliver an extremely open, responsive and transparent tone. They are one of the most curious combinations in the Duesenberg lineup. PLEK PROCESSED A pleked fretboard guarantees perfectly level frets. This is the basis for our fret polishing and setup work all done by hand that eventually makes our instruments play like nothing you have ever played before. CUSTOM RADIATOR VIBRATO UNIT It retains everything you love about the original Diamond Deluxe Vibrato and presents it with a new and exciting design. Of course, we added custom gold accents to the vibrato for Joe's personal model. An ultra-smooth mechanism, reliable tuning stability, and easy string changes are just the key aspects of our unique vibrato design. The robust needle and nylon bearing ensure a very responsive Duesenberg feel when using the vibrato arm. The arm itself can freely rotate 360° and can be adjusted to your desired angle and length. The strings can be easily guided to the tuner by simply passing them through the hole in the bar under the arm shaft. LITTLETOASTER & SINGLETWIN PICKUPS The Duesenberg LittleToaster pickup delivers crystal clear treble tone in the bridge position, while the state-of-the-art Duesenberg SingleTwin Mini with noise canceling ensures clear, classic neck sound in all situations. This was a request from Joe himself; as a serious guitarist himself, he likes to play around with guitar hardware, often resulting in weird hardware finish mixes. For this reason, Joe Walsh Alliance series hardware is made of a mixture of nickel and gold.

Specification

NECK

• Type: Set Neck, 1-piece Maple
• Width: 42.5 mm / 1.67" (nut), 52 mm / 2.05" (12th fret)
• Thickness: 21 mm / 0.8" (1st fret), 24 mm / 0.95" (12th fret)
• Shape: Medium D
• Fingerboard: Indian Rosewood, radius 305 mm / 12"
• Inlays: Morse code inlays
• Frets: 22 Jumbo 2.8 x 1.0 mm
• Scale length: 648 mm / 25.5"
• Trussrod: Steel dual-action
• Headstock: Matching body colour

BODY

• Type: Semi-hollow with sustain block, bent sides, f-hole
• Top: Laminated Spruce
• Back, sides: Laminated flamed Maple
• Dimensions: 46 x 34 cm / 18.11" x 13.38"
• Height (sides): 3.5 cm / 1.4"
• Special artwork: Tibetan Knot Decal
• Binding: Cream, 5-layer purfling
• Pickguard: Custom Gold
• Finish: PUR lacquer

HARDWARE

• Tuners: Duesenberg Z-Tuners
• Bridge: Duesenberg Steel Saddle Bridge
• Vibrato System: Duesenberg Radiator Tremola (custom golden grill)
• Strap pins: Duesenberg Standard (Straplock compatible)
• Hardware color: Nickel & gold
• Strings: Duesenberg Custom 10/50 (010-013-017-028-042-050)

ELECTRICS

• Pickup (neck): Duesenberg SingleTwin Mini
• Pickup (bridge): Duesenberg LittleToaster
• Wiring: 1 Volume, 1 Tone, 3-Way Pickup Selector

ACCESSORIES

• Case: Custom Line Case (included)
• Tools: All required allen keys (included)
