An ultra-smooth mechanism, reliable tuning stability, and easy string changes are just the key aspects of our unique vibrato design. Diamond Deluxe is lightweight yet provides great sound. The robust needle and nylon bearing ensure a very responsive Duesenberg feel when using the vibrato arm. The arm itself can freely rotate 360° and can be adjusted to your desired angle and length. The strings can be easily guided to the tuner by simply passing them through the hole in the bar under the arm shaft.

Features

• Solid-Body - Beautifully contoured body made from Alder. Solid-Body constructions deliver instant response, a lot of attack and sustain and perfect feedback resistance. Alder is a popular tone-wood known for its bright voice and versatility.
• Pickups - Fitted with our classically voiced GrandVintage humbucker in the bridge position. Accompanied by two specially designed singlecoils for transparent tone and funky in-between sounds. Robust 4-Way pickup selector switch.
• Plek Processed - A Plek processed fretboard guarantees perfectly level frets. This is the basis for our multi-step fret polishing and setup work all done by hand that eventually makes all our instruments play like nothing you have ever played before.

Specifications

Neck

• Type: Set Neck, 1-piece Maple
• Width: 42.5 mm / 1.67" (nut), 52 mm / 2.05" (12th fret)
• Thickness: 21 mm / 0.8" (1st fret), 24 mm / 0.95" (12th fret)
• Shape: Medium D
• Fingerboard: Indian Rosewood, radius 305 mm / 12"
• Inlays: Pearloid diamonds
• Frets: 22 Jumbo 2.8 x 1.0 mm
• Scale length: 648 mm / 25.5"
• Trussrod: Steel dual-action
• Headstock: Black

Body

• Type: Solidbody, Alder
• Dimensions: 46 x 34 cm / 18" x 13.4"
• Height (sides): 4.2 cm / 1.7"
• Binding: Cream
• Pickguard: Black
• Finish: PUR lacquer. Back and sides Trans-Black.

Hardware

• Tuners: Duesenberg Z-Tuners
• Bridge: Duesenberg Steel Saddle Bridge
• Vibrato System: Duesenberg Diamond Deluxe Tremola, short version
• Strap pins: Duesenberg Standard (Straplock compatible)
• Hardware color: Nickel
• Strings: Duesenberg Custom 010/050 (010-013-017-028-042-050)

Electrics

• Pickup (neck): Duesenberg Alnico Blade Singlecoil
• Pickup (middle): Duesenberg Pearlito Singlecoil
• Pickup (bridge): Duesenberg GrandVintage Humbucker
• Wiring: 1 Volume, 1 Tone, 4-Way Rotary Switch

Accessories

• Bag: Duesenberg Custom Line Bag (included)
• Case: Duesenberg Custom Line Case for Paloma (available separately)
• Tools: All required allen keys included
