Paying tribute to guitar hero Jimi Hendrix, this special edition Band of Gypsys Fuzz features a custom finish with the famous 1968 Shrine Auditorium concert poster by revered rock artist John Van Hamersveld, remixed by Simon Berndt of One Horse Town Illustration with star-spangled flair and psychedelic lettering to spotlight Hendrix's enormous contribution to that mind-melting mojo of that historical event.

Constructed inside a mini MXR chassis, the Authentic Hendrix '68 Shrine Series Uni-Vibe Chorus/Vibrato delivers all the thick, authentic modulation and textures found all over the groundbreaking Band of Gypsys record in all their glorious wonder, at a fraction of the size of the original Shin-ei unit used by Hendrix between 1969 and 1970.

Specifications

• VIBE OFF
  • Input Impedance: 600kΩ
  • Output Impedance: (Full Volume - 29kΩ) (Half Volume - 33kΩ)
  • Max Input: 0dBV
  • Max Output: 8dBV
  • Speed Control: 0.5Hz to 10.5Hz
  • Noise Floor: -97dBV
  • Bypass: True Hardwire
• VIBE ON
  • Input Impedance: 730kΩ
  • Output Impedance: (Full Volume - 180kΩ) (Half Volume - 33kΩ)
  • Max Input: 0dBV
  • Max Output: 27dBV
  • Speed Control: 0.5Hz to 10.5Hz
  • Noise Floor: -97dBV
  • Bypass: True Hardwire
• Power
  • Power Supply: 9V DC
  • Current Consumption: 5mA
