The EHX Nano Metal Muff was built for the player who demands nothing less than hard-hitting distortion and an intense, aggressive sound.

It’s a combination of weaponized distortion and an extremely powerful EQ section that provides all the flexibility and tone-shaping needed to dial in an array of ultra-heavy sounds.

The Nano Metal Muff’s newly designed noise gate is a superb addition to this high-gain pedal and eliminates unwanted hum when you stop playing.

It features a noise floor threshold control (GATE) and its own LED to indicate when the gate is engaged.

A compact footprint and intelligent, straight forward controls complete the picture.

---

Features

• Voiced for the heavy metal player
• Compact, pedalboard friendly footprint
• Extensive EQ control: Bass +/- 14dB of cut or boost, Mid +/- 15dB and Treble +/- 10dB
• VOL (volume) sets the pedal’s output volume level
• DIST adjusts input gain and distortion
• Noise gate eliminates unwanted noise and includes an LED to indicate when the output signal is muted
• 9V battery included

---

Specifications

• Circuit: Analog
• Bypass: Buffered Bypass
• Audio: Mono
• Power Supply: 9V battery included (optional 9.6VDC-200mA power adapter not included)
• Dimensions (in): 4.5 x 2.75 x 2.1
• Current Draw: 24 mA
• Year Released: 2021
• UPC: 683274012322

---
