Specifications

• Four-knob design provides excellent control and gives the user the ability to precisely shape their instrument’s dynamics.
• The Sustain knob controls the amount of compression applied to the guitar signal.
• The Attack know adjusts how quickly the compressor recovers. As Attack is turned clockwise the pedal’s response is slower and more initial pick attack comes thru.
• The Blend knob adjusts the mix of the dry and compressed signals.
• Volume controls the overall output level.
• The Pad switch pads down the input signal to prevent undesirable distortion if the Tone Coret is used with high output humbuckers, bass guitar, etc.
• True Bypass for maximum signal path integrity.
• 9-Volt battery included, also accepts optional EHX 9.6VDC-200mA power supply
• Current Draw: 9mA @ 9VDC
• Dimensions in inches: 2.75(w) x 4.5(l) x 2(h)
• Dimensions in mm: 70(w) x 115(l) x 51(h)
