A powerful, rechargeable battery, combined with unique power management circuitry, is specifically designed to maximize output levels and playing time.

With the addition of Bluetooth® wireless connectivity, you can now easily and neatly add backing tracks or other accompaniment to your performances, jams, or wherever your Loudbox Mini Charge takes you and your music.

---

Features

• Rechargeable battery power
• Bluetooth® 4.0 Connectivity
• Dedicated Instrument and Mic Channels with Input Gain Controls
• Mix D.I. output
• Digital Reverb & Chorus
• 1/8” Auxiliary Input
• Balanced XLR D.I. output
• Lightweight & Portable

---

Specifications

POWER: 60 Watts with Master Volume
DRIVERS: Woofer 6.5” paper cone Tweeter 1” soft dome
SPL: 108dB SPL at 1 meter
SPEAKER BAFFLE: 10° built-in tilt
FREQUENCY RESPONSE: 80Hz – 20kHz
BATTERY LIFE ESTIMATE: 18 hours (low volume), 12 hours (average volume), 4 hours (full volume)
BATTERY CHARGE TIME: 10 hours
CONNECTIVITY: Bluetooth® 4.0
DIMENSIONS: 12" H x 13.7" W x 9.7" D (305 mm x 349 mm x 247 mm)
WEIGHT: 21.2 lbs (9.6 kgs)
WALL CHARGER: Included

---

Instrument Channel

• 1/4" input for active or passive pickups
• Feedback-fighting Phase switch
• 3-band EQ with low, mid, and high tone controls
• Reverb level
• Dual-function Chorus

---

Mic Channel

• XLR input for dynamic microphones
• 2-band EQ with low and high tone controls
• Reverb level

---

Optional Accessories

12V WALL CHARGER: ACC-PWC-AU5 (Australia)

---

Watch: The Loudbox Mini Charge
