Dunlop engineers worked closely with the world's top guitar players to design the 535Q Cry Baby Multi-Wah, a pedal that allows you to fine-tune your wah sound and make it your own.

This is the Swiss Army knife of wah pedals. Its six-position Range Selector control allows you to choose from six different frequency ranges, each position based on the unique tonal characteristics of our most prized wah specimens. The Variable Q control allows you to take the 535Q's response from narrow and sharp to broad and subtle with the twist of a control. Once you've got your sound, make sure it gets heard with the switchable boost-adjustable up to +18dB-that can create endless sustain on any note.

The 535Q provides control over the most important wah parameters so you can create your ultimate wah tone.

---

Specifications

Impedance
Input: 1 MΩ
Output: 1 kΩ

Signal to Noise Ratio*
Heel Down: 90 dBV
Toe Down: 97 dBV

Wah Range Selector
1st Position (Full CCW): 440 Hz to 2.2 kHz
2nd Position: 400 Hz to 1.9 kHz
3rd Position: 375 Hz to 1.8 kHz
4th Position: 345 Hz to 1.6 kHz
5th Position: 395 Hz to 1.4 kHz
6th Position: 250 Hz to 1.2 kHz

Filter Gain**: 15 dB
Boost Control Range: 0.1 dB to 17 dB
Bypass: True Hardwire
Current Draw: 2.5 mA
Power Supply: DC 9 volts

---
