Specifications

Impedance

• Input 1 MΩ
• Output 1 kΩ

Resonant Frequency

• Heel Down 180 Hz
• Toe Down 1800 Hz

Output Characteristics

• Maximum Level +7.5 dBV
• VOL Control (Volume) 0dB/-21 dB
• Heel Down Gain* +22 dB / +8.5 dB
• Toe Down Gain** +32 dB / +12.5 dB

Bypass

• Automatic Buffered
• Delay** 35ms to 550ms
• Delay Factory Preset 290ms

Noise Floor***

• Bypass -100 dBV
• Heel Down (Effect On) -94 dB
• Toe Down -87 dBV

Current Draw

• 6.7mA

---

WATCH: 105Q Cry Baby Mini Bass Wah
