Based on a simple trigger waveform, wave folder and overdrive are used to add overtones and distortion, and then a waveguide resonator effect brings the sound to life. The six-part DSP synth engine was designed with a completely different philosophy than conventional drum machines, and generates a wide range of unexpectedly different sounds. And of course, you can play those sounds from the volca-style sequencer.

Adding these distinctive sounds to your rhythms will revolutionarily transform your performances and productions.

---

Features

• Digital percussion synth with a 6-part x 2-layer structure
• Distinctive sound from a newly developed DSP engine
• Waveguide resonator adds rich resonances
• 16-step sequencer with a wide range of parameter automation
• 16-step sequencer with a wide range of parameter automation
• Slice function finely divides a step to allow drum-rolls
• An accent function that can be specified in 16 levels
• A convenient choke function lets you specify grouping for parts
• Two randomize functions expand your inspiration
• Novel design featuring a custom LCD
• Synchronized performance with other volca and electribe units, and with your DAW
• Compact, size, battery operation, and built-in speaker mean that you can take this unit anywhere and enjoy playing on the go.

---

Specifications

Keyboard: Multi touch trigger pads / Step keys

Synthesizer

• Type: Digital synthesis
• Maximum Polyphony: 6
• Structure: 6 parts (For each part, 2 oscillators, pitch modulator, and amp EG), waveguide resonator effect.
• Kits: 16 (Settings for 6 parts + Settings for waveguide resonator) Kit No.1 – No.10 are factory preset.
• Program: 16 (Sequence pattern, Motion sequence, Kit No.) Program No.1 – No. 10 are factory preset.

Sequencer

• Number of parts: 6
• Number of steps: 16 (pattern chain is available)
• Number of recording patterns: 16

Connectors

• Audio Output: Headphones jack (3.5mm stereo mini jack)
• Sync: Sync In jack (3.5mm monaural mini jack, Maximum input level: 20V); Sync Out jack (3.5mm monaural mini jack, Maximum Output level: 5V)
• MIDI: MIDI IN

Power

• Battery Life: Approximately 10 hours (using alkaline batteries)
• Power supply: AA alkaline battery × 6, AA nickel-metal hydride battery × 6, or KA-350 AC adapter (sold separately)

Others

• Included Items: AA alkaline battery × 6 (for verifying operation), Sync cable
• Accessories (sold separately): KA-350 AC adapter, SEQUENZ CB-4VOLCA hard shell case, SEQUENZ CC-VOLCA soft shell case, SQ-CABLE-6 Sync cable
• Dimensions (W x D x H): 193 × 115 × 39 mm / 7.61 x 4.54 x 1.54 inches
• Weight: 370 g / 0.75 lbs. (Excluding batteries)
