LD Systems G3 Series MON 12 A 1200W 12 inch Active Coaxial Stage Monitor
12"/1" stage monitors have been a satisfying medium for decades in terms of sound quality, sound pressure and portability. With its coaxial construction, smart electronics and professional optics, the MON 12 A G3 brings this concept into the "modern era". Its optimal radiation shapes of 50° x 90° for monitor applications and 90° x 50° for FOH applications make it an all-rounder offering the right solution for many tasks.
Both the signal (XLR/jack combo) and the power connection (PowerCON compatible) can be looped through. This allows for elegant and tidy cable routing in case of multi-monitor setups or distributed sound reinforcement.
Features
- Compact high-performance stage monitor with top-of-the-range technologies
- Class-D power amplifier with 300 W RMS/1200 W peak and 127 dB max. SPL
- Coaxial design for true point source with a 1.75" titanium-diaphragm HF driver
- 12" woofer with 2.5" voice coil
- Optimised, practical radiation pattern due to 50° x 90° CD horn
- DynX® DSP (Gen.2) for distortion-free sound even at maximum volume
- 3-band EQ, Notch filter, 4 application presets and delay function
- PowerCON compatible loop-through professional power connection
- 35 mm speaker stand flange for FOH applications
- Durable Polyurea coating and heavy-duty front grille
Specifications
General
Product type: Stage monitors
Type: Powered
Colour: Black
System output (RMS): 300 W
System output (Peak): 1200 W
Max. SPL Average (Sine burst): 120 dB (100 Hz - 12 kHz, fullspace @1m, 10% THD)
Max. SPL Peak (Sine burst): 127 dB (fullspace @1m, 10% THD)
Frequency response (-3 dB): 68 - 18000 Hz
Frequency response (-10 dB): 55 - 20000 Hz
Crossover frequency: 1400 Hz
Monitor angle: 33°
Dispersion (H x V): 50° x 90°
Features: 3-band EQ (High, Mid, Low), 4 Application presets, Delay line, Notch filter
Product Dimensions and Weight:
Width: 425 mm
Depth: 453 mm
Height: 315 mm
Weight: 17,4 kg
Low/mid Woofer
Low/mid Woofer dimensions: 12 "
Woofer dimensions (mm): 304.8 mm
Woofer magnet: Ferrite
Woofer brand: Custom-made
Woofer type: Coaxial loudspeaker
Woofer voice coil (inch): 2.5 "
Woofer voice coil (mm): 65 mm
Cabinet construction: Bass Reflex
Cabinet material: 15 mm Birch Plywood, 15 mm MDF
HF
Horn: CD Horn
Tweeter dimensions: 1 "
Tweeter dimensions (mm): 25.4 mm
Tweeter magnet: Ferrite
Tweeter brand: Custom-made
Tweeter voice coil: 1.75 "
Tweeter voice coil (mm): 44.45 mm
Amplifier module (integrated)
Amplifier: Class D
Protection circuits: Multiband limiter, over voltage, over-current, thermal overload
Operating Temperature: 0 - 40 °C
Humidity Range: < 80 % ( non-condensing )
Fuse: T4AL 250 V
Controls: On / off switch, Rotary/push encoder
Indicators: LC display
Power supply: SMPS
Operating voltage: 100 V AC - 240 V AC, 50 - 60 Hz
Power consumption: 150 W
Power in / out: PowerCON compatible
Line inputs: 2
Line input connectors: 6.3 mm jack, XLR - combo
Line thru: 2
Line through connector: XLR
$717.97
