It consists out of two phase-aligned capsules, a condenser and a dynamic one. You can switch between three sounds for more flexibility for studio and live applications.

Unique sound for bass drums and other bass-heavy instruments.

We put two phase-aligned microphones in a single housing. The dynamic side ensures accurate attack reproduction of the kick drum, while the condenser element captures the drum's low end. Each element has a dedicated output.

This enables you to shape the kick drum sound in unique ways.

---

Features

• Dual-element instrument microphone
• Dynamic and condenser capsule in one housing
• Separate outputs for both capsules
• For kick drum and other bass-heavy sources
• Three switchable sound characteristics
• Cardioid polar pattern

---

Specifications

• Type: Dynamic, moving coil, Condenser, permanently polarized
• Acoustical operating principle: Pressure gradient transducer
• Transducer Ø: 31.7 mm, 1.25 in
• Transducer Ø: 22.4 mm, 0.88 in
• Polar pattern: Cardioid
• Frequency range (dynamic): 20 ... 16,000 Hz
• Frequency range (condenser): 20 ... 20,000 Hz
• Sensitivity, = // = FFR:

  • 0.4 mV/Pa (-69 dBV), dynamic
  • 2 mV/Pa (-54 dBV), condenser
• Sensitivity, + // = Dynamic EFR:

  • 0.4 mV/Pa, -69 dBV/Pa, dynamic
  • 2 mV/Pa, -54 dBV/Pa, condenser
• Sensitivity, + // + Dual EFR: Condenser and dynamic matched at 1 mV/Pa, -60 dBV
• Equivalent noise level: 28 dB (A)
• Max. SPL for 0.5 % THD: 150 dBSPL, 0 dB pre-attenuation
• Dynamic range of mic. amp. (condenser): 122 dB
• Pre-attenuation pad:

  • 0 dB
  • -10 dB
  • -20 dB
• Rated impedance dynamic: 500 Ω
• Rated impedance condenser: 200 Ω
• Supply voltage: 48 V ± 4 V
• Current consumption: 2 mA
• Connector: Gold plated 3-pin and 5-pin XLR
• Cable: 1.5 m (4.95’) dual shielded Y-cable, 5-pin XLR into two 3-pin XLRs
• Microphone dimensions: 71 dia. x 158 mm, 2.8 dia. x 6.2 in
• Microphone net weight: 755 g, 27.3 oz
