Features

PLAY AT HOME
With an emulated output and power reduction to 0.1W the DSL1 is perfect for recording and playing in the bedroom. We have specifically engineered for a great sound at low levels so, you can reduce power to 0.1W.

CHOOSE YOUR TONE
Using the two footswitchable gain channels you can go from clean, classic tones to those with added distortion and extra bite.

SELECT YOUR SOUND
Create the music you want using the studio quality reverb, tone shift and FX loop.

---

Specifications

GENERAL

• Model: DSL1C
• Range: DSL
• Range: Valve
• Channels: 2, ultra gain and classic gain

ELECTRONICS

• Output wattage: 1W with optional power reduction to 0.1W
• Outputs: 1 x 1/4" jack speaker output, 16Ω load only, 1 x 3.5mm jack emulated line out
• Inputs: 1 x 1/4" instrument jack, 1 x 3.5mm jack aux in, footswitch
• Controls: Classic gain channel with volume, ultra gain channel with gain and volume control, channel select switch, tone shift switch, treble, middle, bass, reverb and power reduction option
• Effects: Digital reverb
• Effects loop: Yes, series, send/return

VALVES

• Preamp valves: 2 x ECC83
• Power amp valves: 1 x ECC82

ACCESSORIES

• Footswitch: PEDL-90011 included
• Cable: Detachable power cable included

DIMENSIONS (INCLUDING FEET AND HANDLE)

• Weight: 7.9 kg / 17 lbs
• Depth: 215 mm / 8.5"
• Width: 360 mm / 14.2"
• Height: 340 mm / 13.4"

---
