Features

Play Anywhere
Match your sound to your environment and switch between full power and half power.

Dial In Your Tone
Each channel comes with two modes for a bigger range of tonal possibilities.

Switch Up Your Sound
Craft your perfect sound with presence, resonance and tone shift controls. With individual reverb settings per channel and an FX loop, the DSL40C gives you more sonic control.

---

Specifications

GENERAL

• Technology: Valve
• Channels: 2 (Split)

ELECTRONICS

• Output wattage: 40 w
• Outputs: Speaker outputs: 3 x 1/4" jack sockets (16Ω load / 8Ω load)
• Inputs: 1 x 1/4" instrument input jack
• Controls: Classic gain channel: Gain level, Clean/crunch select, Volume, Channel select, Ultra gain channel: Gain level, Lead 1 / Lead 2 button, Volume, Treble, Middle, Bass, Tone shift, Presence control, Resonance control, Reverb (classic gain channel), Reverb (ultra gain channel),
• Pentode/triode power reduction switch (on rear)
• Effects: Reverb
• Effects loop: Yes, Send/Return with bypass switch

SPEAKERS

• Speaker configuration: 1x12"
• Speaker model: Celestion Seventy 80 G12P-80 (80W, 16Ω)
• Unit impedance: 16Ω

VALVES

• Preamp valves: 4 x ECC83
• Power amp valves: 2 x EL34

ACCESSORIES

• Footswitch: Originally shipped with PEDL-00009 which was replaced by PEDL-91004
• Cable: Detachable power cable included, Speaker cable included

DIMENSIONS (INCLUDING FEET AND HANDLE)

• Weight: 23.7kg / 52.2lbs
• Width: 621mm / 24.4"
• Height: 490mm / 19.3"
• Depth: 252mm / 10"

---

WATCH: DSL40C Product Demo
