Features

PLAY AT HOME
You can reduce power to 0.5W and use the emulated output making this amp is ideal for those quieter moments.

CHOOSE YOUR TONE
Using the footswitchable gain channels the DSL delivers anything from clean, classic tones to heavy distortion with extra bite.

SELECT YOUR SOUND
The studio quality reverb, tone shift, deep and FX loop features allows for you to add depth and shaping to your sound.

---

Specifications

GENERAL

• Range: DSL
• Range: Valve
• Channels: 2 (Split)

ELECTRONICS

• Output wattage: 5W (with power reduction option, 1W)
• Outputs: 1 x 1/4" jack speaker output, 16Ω load only, 1 x 3.5mm jack emulated out
• Inputs: 1 x 1/4" jack instrument input, 3.5mm jack Aux in, footswitch
• Controls: Classic gain channel (gain, volume), channel select, ultra gain channel (gain, volume), tone shift button, treble, middle, bass, deep EQ shift, reverb, low power option (on rear)
• Effects: Digital reverb
• Effects loop: Yes, series, send/return

SPEAKERS

• Speaker configuration: 1x10"
• Speaker model: Celestion Ten-30 speaker (16Ω, 30w)
• Unit impedance: 16Ω

VALVES

• Preamp valves: 2 x ECC83
• Power amp valves: 1 x 12BH7

ACCESSORIES

• Footswitch: PEDL-90012 included
• Cable: Detachable power cable included

DIMENSIONS (INCLUDING FEET AND HANDLE)

• Weight: 12.7 kg / 28 lbs
• Depth: 240 mm / 9.4"
• Width: 455 mm / 17.9"
• Height: 425 mm / 16.5"

---
