All of these elements are controlled by the two SHARC DSP chips with an intuitive user interface and professional control features and I/O options, giving the player complete control whether on stage or in the studio. Other features include a programmable stereo effects loop, a 30-second looper station that lets you save loop sessions, external device switching, direct USB audio, and more!

Features

• High-quality AMP models that utilize MOOER’s non-linear digital amp modelling technology and IR-based speaker cab models to emulate the same dynamics and feel of a real tube amp.
• TONE CAPTURE allows you to sample and capture your real-life amplifier, stompbox, Guitar, or cabinet to create brand-new digital sound models.
• 108 preamp models captured from real-life amplifiers, 164 high-quality effects, and 43 IR-based factory speaker cab models. Support for up to 2048 sample pt. third-party impulse response files.
• Programmable FX LOOP with optional signal chain routing for easy integration of your favorite effects and ultimate flexibility for 4 cable method and stereo amp setups.
• Stereo outputs (1/4” and XLR) with independent signal chain routing. Flexibility to send different parts of your virtual rig to different devices.
• MIDI IN/MIDI OUT/THRU with easy mapping and external ctrl switching to control your other pedals and amps.
• Programmable footswitches with user selectable LED colors and assignable functions allowing complete user customization of the control scheme.
• Intuitive and simple UI makes for fast and easy creation of tone presets.
• Supports up to two external expression pedals.
• 30-second stereo loop station
• High-precision, adjustable TUNER.
• Connect to your Mac or Windows PC to create and edit presets, upload IRs, update the firmware, and control MIDI functions.

Connections

• Guitar/Line switch Switch input level between guitar and line level.
• AUX IN 1/8” stereo jack to connect external media devices for audio playback.
• 1/4‘’ INPUT Instrument input
• EXP1/EXP2 ¼” stereo jack/external expression pedal input. Can be set as AMP CTRL for channel switch control of amplifier.
• SEND/RETURN Mono effects loop
• OUTPUT 2 x ¼” mono jack
• PHONES Dedicated headphone output. ¼” stereo jack
• XLR OUT 2 x Balanced XLR output with Ground/Lift switch.
• MIDI port For MIDI IN/OUT (can be set up to MIDI IN/OUT manually)
• USB USB Type-B port to connect to record direct digital audio.
• Interface with official MOOER software to edit and import/export presets and update firmware.
• I/O Power ON/OFF switch.
• DC IN Connect GE300 Lite power supply.

Specifications

---

Algorithm NO. of Effect Blocks: 13 NO. of Effect Types: 315 Patches: 255 (Preset) Format: .wav Sampling Rate: 44.1kHz Sampling Accuracy: 24bit Sampling Points: 2048 Points

---

Input Input Type: 1/4"unbalanced mono audio jack Impedance: Guitar: 1Meg ohm Maximum Input: Line: 10k ohm Level: 6.5 dBu Return Type: 1/4"unbalanced mono audio jack Impedance: 1Meg ohm Maximum Input Level: 9.2 dBu Aux In Type: 1/8"unbalanced stereo audio jack Impedance: 10k ohm Maximum Input Level: 12.4 dBu A/D Conversion Sampling Rate: 44.1 kHz Sampling Accuracy: 24bit Dynamic: 114 dB Frequency: 20Hz ‒ 20kHz, +0/ -1 dB

---

Output Output Type: XLR balanced output X 2 Impedance: 300 ohm Maximum Output Level: 14.6 dBu XLR Output Type: XLR balanced output X 2 Impedance: 300 ohm Maximum Output Level: 14.6 dBu Send Type: 1/4" unbalanced stereo audio jack Impedance: 16 ohm Maximum Output Level: 13 dBu Phones Type: 1/4" unbalanced stereo audio jack Impedance: 16 ohm Maximum Output Level: 13 dBu D/A Conversion Dynamic: 114dB Frequency: 20Hz‒20kHz, +0/-1dB

---

Others MIDI MIDI IN/OUT 5 Pin Female Connector USB Type: USB Type-B USB Audio: USB 2.0, 2 IN 2 OUT, 44.1kHz, 24bit EXP Expression Jack Type: 1/4"TRS jack X 2 Impedance: 10k ‒ 100k ohm Power Supply: 9V 2A (+)-(O)-(-) Product Dimensions: 287mm X 208mm X 64mm Product Weight: 2.1kg Accessories: Power Supply, USB Cable, Quick Guide manual
