Subharmonicon's signature sound begins with two analog VCOs and four subharmonic oscillators, making a total of six powerful sound sources. Each subharmonic tone is mathematically derived from one of the two main VCOs, giving the resulting chord shapes a remarkably consistent quality. Built-in quantisation lets you choose between multiple tuning systems to get the perfect interval every time. Choose from modern equal temperament settings, the heavenly intervals of pure tuning, or the limitless freedom of no quantisation at all. Subharmonicon's distinctive chord shapes are animated by a pair of polyrhythmic four-step sequencers. Each sequencer is clocked by one or all four rhythm generators that output a mathematical division of the master tempo. Stack multiple rhythm generators to create complex polyrhythms and discover inspiring new patterns and styles. Make full use of Subharmonicon's dual envelope generators, Moog Ladder filters, and analog VCAs to obtain dynamic articulations ranging from lush pads and blurry edges to percussive plosives and ritualistic rhythms. Although no patching is required to start creating, exploring Subharmonicon’s modular patchbay unlocks worlds of possibilities as you make novel connections and plug into new ideas. The 32-point 3.5mm patchbay can be patched into itself, expanding Subharmonicon’s onboard capabilities, or interfaced with Mother-32, DFAM, and other external Eurorack-compatible gear (MIDI Type A adapter included for DIN to 3.5mm MIDI input). Use as a standalone synth with included +12V DC power supply or simply remove the front panel to install into any Eurorack system.

Features

• A rich harmonic kaleidoscope
• Design and explore design polyrhythmic patterns that evolve over time.
• Craft a rich harmonic kaleidoscope with six-tone subharmonic chords.
• Integrate with Mother-32 and DFAM for endless possibilities.

Tech Specs

• Type:Semi-modular Desktop Synthesizer and Sequencer
• Analog/Digital:Analog
• Polyphony:Mono
• Presets:6-tone Subharmonic Chords, 4 x Rhythm Generators
• Oscillators:2 x VCO, 4 x Subharmonic
• Waveforms:Sawtooth, Square wave
• Envelope Generator:VCA (attack, decay), VCF (attack, decay)
• Filter:Self-oscillating Ladder Filter, Lowpass, 4-pole (24dB/Octave)
• Sequencer:2 x Sequencers, 4 Steps per Sequencer, Selectable Quantization
• Headphones:Shared
• MIDI I/O:1 x 1/8" TRS Type A (In)
• Other I/O:32 x Patch Points
• Power Supply:12V DC power supply (included)
• Height:4.2"
• Width:12.57" (60HP)
• Depth:5.24"
• Weight:3.5 lbs.
• Manufacturer Part Number:MOD-SUBH
