For lush, liquid textures not possible with digital circuitry, the MXR Analog Chorus employs Bucket Brigade circuitry to create it's stunning, and classically familiar chorusing sounds. With control over Rate, Level, and Depth, the Analog Chorus also boasts controls for cutting High and Low frequencies for the ultimate control over your sound. Like every pedal in the MXR catalog, the Analog Chorus is built in a rugged, heavy-duty housing with robust connection jacks and switches to withstand the rigors of touring and travel.

Features

• Analog bucket- brigade technology
• Small footprint saves pedalboard space
• HIGH and LOW cut controls for detailed tone sculpting
• Two outputs for a wide and sweeping stereo spread

Specifications

• Input Impedance: 1MΩ
• Output Impedance: 1kΩ
• Bypass: Buffered
• Noise Floor (A-Weighted)
  • Effect On: -96dBV
  • Bypass: -106dBV
• Tone Controls
  • LOW: 70Hz to 800Hz, 12dB/oct Shelf
  • HIGH: 660Hz to Flat, 6dB/oct Shelf
• Power
  • Power Supply: 9V DC
  • Current Consumption: 13mA
