When you run your signal from your instrument to your amp though long cables and/or through a large array of effects with varying impedance, there’s bound to be some signal degradation. Placing the CAE Buffer in your signal chain addresses this issue.

It’s a low-noise buffer in a small, rugged housing; it can add up to +6dB of gain with the front-facing gain slider; it makes up for signal loss that can occur when combining effects with different impedance levels; it fine-tunes signal recovery with Hi and Lo cut switches; it has an extra output for a tuner, separate effects chain or amp, and can be set to receive either a buffered or unbuffered signal; it also features a convenient 9VDC power output jack which provides power for another pedal.

The CAE Buffer is truly a mighty utility with a small footprint—an ideal addition to any effects rig or pedalboard!

---

Features

• Low noise buffer in a small, rugged steel housing
• Hi and Lo cut options with indication LEDs
• Adjustable 0 to +6dB gain slider
• Features a pass-through 9-volt jack for other effects

---

Specifications

• Input Impedance: 1 MΩ
• Output Impedance: <1 kΩ
• Max Input: 12 dBV
• Max Output: 19 dBV
• Signal to Noise*: >100 dB
• Frequency Response:
  • 20 Hz – 20 kHz: ±0.1 dB
  • Lo Cut: -6 dB @ 140 Hz
  • Hi Cut: -6 dB @ 7 kHz
• Bypass: True Hardwire Relay
• Current Draw: 43 mA
• Power Requirements: 9 volts DC
