It’s the iconic MASCHINE workflow, with fewer strings attached.

---

Features

• Immersive standalone workflow for creating beats and melodies, sampling, arranging music, and performing on stage or in the studio
• Includes MASCHINE+ Selection with industry-leading instruments, sounds, and effects, plus renowned MASCHINE drum and bass synth plugins and effects
• Quad-core CPU and 4 GB RAM for fast, seamless creation when it counts
• Pro-grade, 44.1 kHz / 24-bit audio interface* with 2 x ¼” TRS line outputs, 2 x ¼” TRS line inputs, ¼” dynamic mic input, stereo headphone output, 1 x MIDI In, 1 x MIDI out; 1 x Footswitch, 2 x USB ports for MIDI controllers / external HDDs
• Robust, anodized aluminium design for years on the road and in the studio
• Iconic MASCHINE features and workflow including 16 velocity-sensitive pads, MASCHINE effects and plugins, swing, pad link, note repeat, step sequencer, and vintage sampler emulation
• Use standalone or with a computer – integrate with your studio workflow, and unplug for DAW-less setups or live performances
• WiFi and Link enabled for wirelessly installing and updating products, collaborating with others, and syncing with other gear

---

Specifications

Line-In

• Full Scale Level: +18,6 dBu
• Dynamic Range: 100 dB
• THD+N: 0.003 %
• Frequency Response: 20Hz-20kHz +/- 0.1 dB
• Crosstalk L/R: -96 dB

Mic Input (max gain)

• Full Scale Level: -32 dBu
• Dynamic Range: 90 dB
• THD+N: 0.01 %
• Frequency Response: 20Hz-20kHz +/- 0.4 dB

Mic Input (min gain)

• Full Scale Level: -3.4 dBu
• Dynamic Range: 102 dB
• THD+N: 0.004 %
• Frequency Response: 20Hz-20kHz +/- 0.15 dB

Line Out

• Maximum Output Level: +18.0 dB
• Dynamic Range: 102 dB
• THD+N: 0.003 %
• Frequency Response: 20Hz-20kHz +/- 0.5 dB
• Crosstalk L/R: -100 dB

Headphone Out

• Maximum Output Level: 29.4 mW @ 33 Ohm load
• Dynamic Range: 102 dB
• THD+N: 0.007 %
• Frequency Response: 20Hz-20kHz +/- 0.35 dB
• Crosstalk L/R: -60 dB

---
