Features

• 3.5-inch (89 mm) woven composite low-frequency transducer
• 1-inch (25 mm), ultra-low-mass, silk-dome, high-frequency transducer
• Rear-firing acoustic port for superior bass-frequency reproduction
• Optimized, resonance-suppressing internal bracing
• High- and low-frequency tuning controls
• Front-panel Volume control for speakers and headphone amplifier
• 50 watt (25W/side), Class AB biamplification
• RF interference, output current limiting, over-temperature, transient, and subsonic protection
• Amplifier “soft start” feature eliminates popping on power-up
• Internal power supply with IEC connector
• Power switch with on/off LED
• Balanced ¼-inch TRS, unbalanced 1/8-inch stereo, and RCA inputs
• Integrated stereo headphone amplifier with front-panel 1/8-inch output

---

Specifications

Inputs

• 1- Stereo 1/8"
• 2- Balanced ¼” TRS
• 2- Unbalanced RCA

Performance

• Frequency Response 80 Hz - 20 kHz
• Crossover Frequency 2.8 kHz
• Amplifier Power 25W/speaker
• LF Driver 3.5"
• HF Driver 1” silk dome
• Peak SPL (@ 1 meter) 100 dB
• Input Impedance 10 kΩ

User Controls

• Volume Range A-type taper
• MF Control Variable (-6 to +6 dB, center 100 Hz)
• HF Control Variable (-6 to +6 dB, center 10 kHz)

Protection

• RF interference
• Output-current limiting
• Over-temperature
• Turn-on/off transient
• Subsonic filter
• External mains fuse

Power

• 100-120V ~50/60 Hz or 220-240V ~50/60 Hz

Cabinet

• Vinyl-laminated, medium-density fiberboard

Physical

• Width 5.6" (141 mm)
• Depth 6.4" (162 mm)
• Height 8.3" (210 mm)
• Weight (per pair) 6.4 lb. (2.9 kg)

---
