Built for players who are serious about stereo, REPLAY BOX combines stereo ins and outs, advanced functions like TAP control and the NOTE DIVIDER, and the processing power it takes to produce legendary T-Rex tone.

---

Features

• Analog dry signal
• Tap tempo footswitch
• Pristine and clear sound
• Up to 3 seconds of delay
• Incredibly small form factor
• Runs on standard 9VDC power
• True stereo operation (L/R inputs and outputs)
• Subdivision switch - allows choice of quarter, triplets or the sought-after dotted eighth delay

---

Specifications

• Input impedance @ 1KHz: Higher than 1M Ohm
• Output impedance @ 1KHz: Lower than 1K Ohm
• Power supply: 9V DC (T-Rex FuelTank)
• Minimum power supply voltage: 8,5V DC
• Maximum power supply voltage: 12,5V DC
• Current draw @ 9V DC: 110 mA
• Maximum input signal V p-p: 3V p-p
• Battery type: 9V battery 6F22
• Battery life: 30 minutes
• External connectors: input jack (L), input jack (R), output jack (L), output jack (R), 9V DC jack
• Controls: on/off switch, tap, volume, mix, repeat, tempo, mode
• Pedal size incl. knobs (W x H x D): 60 x 50 x 115 mm / 2,4 x 2 x 4,5 inch
• Weight excl. packaging: 0,27 kg / 9,52 oz

---
