Features

• Traditional western body
• Solid spruce top
• Mahogany back & sides
• Amazing sounding reverb/chorus built-into the guitar with no need for external amplification or effects
• New scalloped bracing for louder, richer acoustic sound

---

Specifications

• Body Shape: Traditional Western
• Scale Length: 650mm (25 9/16”)
• Body length: 505mm (19 7/8")
• Total Length: 1038mm (40 7/8")
• Body width: 412mm (16 1/4")
• Body depth: 100-118mm (3 15/16" - 4 5/8")
• Nut width: 43mm (1 11/16")
• String spacing: 11.0mm
• Top material: Solid Spruce
• Back material: Mahogany
• Side material: Mahogany
• Neck material: Nato
• Fingerboard: Rosewood
• Fingerboard radius: R400mm (15 3/4")
• Bridge: Rosewood
• Nut material: Urea
• Saddle material : Urea
• Bridge pins: Black ABS with White Dot
• Tuners: Die-cast Chrome(TM29T)
• Body binding: Cream
• Soundhole inlay: Black + White
• Pickguard: Transparent
• Body finish: Gloss
• Neck finish: Matt
• Electronics: SYSTEM70 TransAcoustic + SRT Piezzo Pickup
• Controls: Reverb / Chorus / TA Switch / Line Out Vol
• Connections: Line Out
• Strings: Elixir NANOWEB 80/20 Bronze Light
• Accessories: Hex Wrench, 2 x AA Batteries
• Case/Bag: not included

---
