Features

Extraordinarily expressive and realistic Voices
The sonic quality of every Voice in Genos is beyond any other Digital Workstation you’ve ever played—this instrument is quite simply a game changer. Everything you hear, whether it be the beautiful CFX piano, the lush strings or the punchy new Revo Drums, it just blows you away!

Powerful DSP effect processing for enhancing the sound
From Reverb to Distortion, Rotary Speaker to Compressor, Genos boasts unprecedented DSP power. Using the same VCM technology as Yamaha’s professional high-end mixing consoles, Genos has the tools to create a perfect sound. Not only do the effects sound great, they look great, too—with stunning graphical user interfaces.

Accompaniment Styles
Whatever genre of music you wish to perform, Genos is ready to accompany you with world-class arrangements, punchy drums and up to four times the DSP power of previous Digital Workstations. Never has there been a more perfect personal backing band.

Versatile real-time controller—LIVE CONTROL
Instantly shape your sound with the all new LIVE CONTROL surface. A wide variety of functions can be assigned to the LIVE CONTROL knobs and sliders with the LIVE CONTROL view providing instant visual confirmation of your adjustments without interrupting the main display.

Voice and Style expandability with the Yamaha Expansion Manager
With Yamaha Expansion Manager software on your computer you can continually expand the onboard content of your Genos by creating and installing your own custom or purchased Packs. Supporting WAV, AIFF and even SoundFont and REX formats, the scope of possibilities for new sounds and styles is virtually unlimited.

Quick and easy set up with Playlist and Registration
Playlist is the new way to quickly setup Genos, no matter how large your repertoire is. Organize your Registration Memories into convenient Playlists for instant recall during performance.

Audio Function
Cross fade between two audio files with the new Dual Player or assign your own audio data on the Multi Pad, the creative potentials are huge. You can even record your performance directly to a high quality audio file ready to easily share.

---

Specifications

Control Interface

• Number of Keys: 76
• Type: Organ (FSX), Initial Touch/Aftertouch
• Touch Response: Normal, Easy1, Easy2, Soft1, Soft2, Hard1, Hard2
• Joystick: Yes
• Control Knobs: 6 Live Control knobs (Assignable)
• Sliders: 9 Live Control sliders (Assignable), Cross Fader
• Art. Switches: 3
• Display Type: Main Display : TFT Color Wide VGA LCD | Sub Display: OLED (Live Control view)
• Size: Main Display : 800 x 480 dots (9 inch) | Sub Display: 589 x 48 dots
• Touch Screen: Main Display : Yes
• Language: Main Display : English, German, French, Spanish, Italian | Sub Display: English
• Panel Language: English

Voices

• Tone Generating Technology: AWM Stereo Sampling, AEM technology
• Number of Polyphony: (Max.) 256 (max.) (128 for Preset Voice + 128 for Expansion Voice)
• Number of Voices: 1,652 Voices + 58 Drum/SFX Kits
• Featured Voices: 10 Revo! Drums/SFX, 76 Ensemble, 390 Super Articulation!, 75 Super Articulation2!, 82 MegaVoice, 40 Sweet!, 81 Cool!, 160 Live!, 24
• Organ Flutes!
• Compatibility:

  • XG Yes (for Song playback)
  • GS Yes (for Song playback)
  • GM GM (for Song playback)
  • GM2 GM2 (for Song playback)
  • Part Right 1, Right 2, Right 3, Left

Expandability

• Capacity Voice: Yes (approx.3.0GB)
• Style & Voice Set: Yes (Internal Memory)

Effects

• Types Reverb: 59 Preset + 30 User
• Chorus: 107 Preset + 30 User
• DSP: Variation: 358 Preset(with VCM) + 30 User | Insertion 1–28: 358 Preset(with VCM) + 30 User
• Master Compressor: 5 Preset + 30 User
• Master EQ: 5 Preset + 30 User
• Part EQ: 28 Parts
• Number of Presets: Vocal Harmony: 54 | Synth Vocoder: 20
• Number of User Settings: 60 * The number is the total of Vocal Harmony and Synth Vocoder
• Vocal Effect: Mic Effect: Noise Gate, Compressor, 3 Band EQ | Vocal Effect: 23

Accompaniment Styles

• Number of Preset: Styles 550
• Featured Styles: 491 Pro, 39 Session, 10 Free Play, 10 DJ
• Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
• Style Control: INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
• One Touch Setting: (OTS) 4 for each Style
• Chord Looper: Yes
• Style Section Reset: Yes
• Compatibility: Style File Format (SFF), Style File Format GE (SFF GE)

Multi Pads

• Preset Number of Multi Pad Banks: 448 Banks x 4 Pads
• Audio Link: Yes

Songs

• Number of Preset Songs: 9 Demo Songs, 11 Preset Songs
• Recording Number of Tracks: 16
• Recording Function: Quick Recording, Multi Track Recording, Step Recording
• Playback: SMF (Format 0, Format 1) , XF
• Recording: SMF (Format 0), approx. 3 MB per Song

Functions

• Audio Recorder/Player Playback: WAV (44.1 kHz, 16 bit, stereo), MP3 (44.1 kHz, 64/96/128/256/320 kbps, stereo)
• Recording: WAV (44.1 kHz, 16 bit, stereo), approx. 0.8 GB (80 minutes) per Song
• Time Stretch: Yes
• Pitch Shift: Yes
• Vocal Cancel: Yes
• Voices Harmony/Echo: Yes
• Arpeggio: Yes
• Panel Sustain: Yes
• Mono/Poly: Yes
• Style Creator: Yes
• OTS Information: Yes
• Multi Pad Creator: Yes
• Number of Buttons: 10
• Control: Registration Sequence, Freeze
• Number of Records: 2,500 (max.) Records per Playlist file
• Score Display Function: Yes
• Lyrics Display Function: Yes
• Search: Registration Bank
• Overall Controls: Metronome Yes
• Tempo Range: 5 – 500, Tap Tempo
• Transpose: -12 – 0 – +12
• Tuning: 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
• Octave Button: Yes
• Scale Type: 9 Types
• Sub Scale Setting: Yes
• Miscellaneous: Direct Access Yes
• Text Display Function: Yes
• Wallpaper Customization: Yes
• Display Out: Yes (by using a commercially USB display adaptor) * For a list of compatible devices, access the “Yamaha Downloads” website. *Genos generates a 800 x 600 size image for external display. The size of Genos main display is 800 x 480, so there will always be blank areas at the top and bottom of the image.

Storage and Connectivity

• Storage Internal Memory: Yes (approx. 58 GB)
• External Drives: USB flash drive
• Headphones: Standard stereo phone jack (PHONES)
• FOOT PEDAL: 1 (SUSTAIN), 2 (ART.1), 3 (VOLUME), Function assignable
• Microphone: Yes (Combo Jack) , Phantom Power (+48V) available
• MIDI: MIDI A (IN/OUT) , MIDI B (IN/OUT)
• AUX IN: L/L+R, R
• DIGITAL OUT: Yes (coaxial)
• LINE OUT: MAIN (L/L+R, R) , SUB (1, 2) , SUB (3, 4 / AUX OUT)
• USB TO DEVICE: Yes (x 3)
• USB TO HOST: Yes
• LAN: Yes (*) , Standards: IEEE802.11b/g/n (IEEE802.11n 5GHz: not compatible) *May not be included, depending on your area. Check with your Yamaha dealer.

Size/Weight

• Width: 1,234 mm (48-9/16")
• Height: 138 mm (5-7/16")
• Depth: 456 mm (17-15/16")
• Weight: Weight 13.0 kg (28 lb, 11 oz)

---
