Features

• Exceptional amplified sound at performance-level volumes
• Solid cedar top
• Solid walnut back and sides
• Walnut fingerboard
• Performance-friendly strap buttons

---

Specifications

• Color/Finish: NT
• Body Shape: Yamaha CG Cutaway Shape
• Scale Length: 650 mm (25 9/16”)
• Body Length: 490 mm (19 5/16")
• Total Length: 990 mm (39")
• Body Width: 370 mm (14 9/16")
• Body Depth: 94-100 mm (3 11/16" - 3 15/16")
• Nut Width: 52 mm (2 1/16")
• String Spacing: 11.8 mm
• Top Material: Solid Western Redcedar
• Back Material: Solid Walnut
• Side Material: Solid Walnut
• Neck Material: African Mahogany
• Fingerboard Material: Ebony
• Fingerboard Radius: Flat
• Bridge Material: Ebony + Walnut
• Nut Material: Urea
• Saddle Material: Urea
• Bridge Pins: None
• Tuners: Gold w/ Matte Black Shaft (RM1388NB-B06)
• Body Binding: Mahogany + Black + White
• Soundhole Inlay: Abalone + Mahogany + Padauk
• Pickguard: None
• Body Finish: Gloss
• Neck Finish: Matte
• Electronics: Atmosfeel (Undersaddle Pickup + Contact Sensor + Mic)
• Controls: Master Vol/Mic Blend/Treble EQ
• Connections: LINE OUT
• Strings: Medium (Yamaha S10)
• Accessories: Hex Wrench, 2 x AA Battery
• Case: Reinforced Carrying Bag (NCX)

---
