Portable Analog Audio Mixing with the Power of Bluetooth The Alto Professional TrueMix 600 is a portable audio mixer with Bluetooth and a built-in stereo USB audio interface that provides all the essential features you need for home recording, live streaming, podcasting, or performance. TrueMix 600 features a dedicated Bluetooth channel for easy streaming from your personal devices. The Bluetooth channel also supports feedback-free phone pairing using Mix-Minus technology. This feature is not supported by other audio mixer series in this class. It has 6 analog inputs with high headroom circuitry to minimize noise and clipping in the signal. The microphone input channel features an XLR input, perfect for connecting dynamic or condenser microphones with 48V phantom power. These channels also feature 1/4-inch balanced line inputs for connecting instruments or other line-level signals. There are also two stereo input channels, each with two balanced 1/4-inch TRS inputs. These inputs are ideal for line-level audio sources. All channels feature a 2-band EQ with color-coded controls, making it easy to dial in the perfect sound, even in low light. Connecting the TrueMix 600 to your computer is also very fast, thanks to plug-and-play connectivity on Windows and macOS. The TrueMix 600 is a compact, feature-packed audio mixer perfect for on-the-go use. Robust Output Routing Whether you're creating music at home, recording a podcast, or live streaming online, being able to hear your voice is essential. TrueMix 600 has a variety of output and routing options to suit any scenario. There are two headphone outputs, each with independent volume controls. If you need to send the audio signal to another destination, such as an external effects processor, there's an AUX send/return and individual AUX send controls on each channel, so you can always tweak the perfect mix. For recording, the USB output sends a copy of the main output to your computer, or you can also connect the 2-track in/out to an external recorder and send it directly to one of the headphone outputs. TrueMix 600 provides everything you need for complete control over your audio routing.

Features

• USB I/O for audio playback and stereo recording
• Dedicated Bluetooth channel with mix-minus return for feedback-free phone pairing
• Dual headphone outputs with independent volume control
• 1/4” Main, Tape, Headphone, and AUX outputs
• Two mic input channels with phantom power and balanced line inputs
• Two stereo input channels with balanced 1/4” TRS jacks
• Two-band EQ on all channels
• 2-track inputs w/ assignable routing: Main Mix or Headphone Out
• Eight-segment LED VU meter for precise level monitoring
• Extra knob caps included in the box for added customization

Specifications

Frequency Response: All inputs: 20 Hz – 22 kHz (±1 dB) THD+N (Total Harmonic Distortion): All inputs: < 0.005% (@ 4 dBu, 1 kHz) Gain Range Mic inputs (Channels 1-2): 0 – 50 dB Line inputs (Channels 1-2): 15 dBu – 35 dBu Line inputs (Channels 3-6): -20 dBu – +20 dBu Max Voltage Gain 70 dB (MIC INPUT to MAIN MIX OUTPUT) 80 dB (MIC INPUT to CTRL ROOM / PHONES OUPTUT) 60 dB (MIC INPUT to AUX SEND) SNR (Signal-to-Noise ratio): All inputs: > 110 dBu Crossover Frequency: Adjacent inputs: < -80 dB @ 1 kHz Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, Channels 1-2, panned hard left or right) Phantom Power: +45 ~ +49V with switch control Impedance Mic inputs: 3.9 kΩ All other inputs: > 10 kΩ Aux outputs: 1 kΩ All outputs: 120 Ω Equalization High: ±15 dB @ 12 kHz Low: ±15 dB @ 80 Hz Bluetooth Profile: A2DP Module: Bluetooth 5.0 Operating Frequency: 2402 MHz – 2480 MHz Range: 100 ft. / 30.5 m Connectors

• (5) 1/4” (6.35 mm) TRS outputs
• (6) 1/4” (6.35 mm) TRS stereo L/R inputs
• (2) 1/4" (6.35 mm) TRS headphone output
• (2) 1/4" (6.35 mm) TRS mono input
• (1) Standard RCA L/R input
• (1) Standard RCA L/R output
• (2) XLR inputs
• (1) USB type-B input
• (1) DC power input

Controls

• (1) Power switch
• (10) volume control knobs (1 per input, 1 aux return, 1 2TK In, 2 headphone out, 1 Bluetooth, 1 Main Out)
• (4) Stereo pan control knobs (1 per input)
• (4) Aux volume control knobs (1 per input)
• (4) EQ Low control knobs (1 per input)
• (4) EQ Hi control knobs (1 per input)
• (4) Gain control knobs (1 per input)
• (3) Locking switch buttons (2 source select, 1 Bluetooth)
• (1) Horizontal sliding switch

Indicators

• (1) Power LED
• (4) Peak LEDs
• (1) Phantom LED
• (16) Main Out Meter LEDs
• (1) Bluetooth LED

Power

• Connection: DC
• Voltage: 18V, 1A
• Consumption: 18W

Product Dimensions

• (width x depth x height)
• 8.9” x 8.5” x 2.9”
• 225.5 x 217 x 74 mm

Product Weight 1.4 kg
