A silent LED house light that boasts the full spectrum of hues with RGBAL LEDs, the Ovation H-605FC comes standard with interchangeable lenses for adjusting for different heights, 5-pin DMX, and integrated terminals for fixed and temporary installations. With a 16-bit dimming response, remote device management, and adjustable PWM (pulse width modulation), the H-605FC avoids flickering, making it perfect for filming applications, as well as live sound and DJ performances.

Features

• Full Color LED (RGBAL), convection cooled houselight
• Interchangeable lens plates to adapt to different mounting heights
• 5-pin XLR and terminal blocks for DMX connections
• Use included yoke for pipe mounting, or suspend from integrated loop-eye
• Virtual Color wheel with color matched to popular gel colors
• Color Temperature Presets from 2800 K to 6500 K with high CRI and CQS
• 16-bit dimming for ultra-smooth fades
• DMX, WDMX and RDM (Remote Device Management) for added programming flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

Taking complete advantage of LED technology, the Ovation H-605FC utilizes the Ovation standard RGBA-Lime color palette, allowing the fixture to recreate almost any other color with stunning accuracy and rendering, along with almost any color temperature of white. Employing superior convection cooling for excellent output, this unit is perfect for theatrical and house of worship applications, and with the addition of W-DMX, RDM, adjustable PWM and a streamlined and user-friendly OLED full-text display, setup and control is more simple than ever before.

Specifications

• Optical
  • Light Source: 60 LEDs (12x Red, 12x Green, 12x Blue, 12x Amber, 12x Lime) 2 to 3W (800mA), 4766K
  • Life Expectancy: 50,000 Hours
  • Colour Temperature (at Full): 4766K
  • CRI (5000K): 90
  • Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25,000Hz
• Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 27Hz
  • Standalone Colour Mixing: Yes
  • Colour Temperature Presets: Yes
  • Dimming Modes: 4
  • Built-In Automated Programs: Yes
• Connections
  • Power Connection: Hard-Wired
  • Data Connectors: 5-Pin XLR, Pheonix Connector
  • Cable Length (Power): 4.5m
• Control
  • Control Protocol: DMX, RDM, W-DMX
  • DMX Channels: 2, 4, 5, 8, 11, 13, 14, 16 or HSV
  • Modes/Personalities: 9 Personalities (2, 4, 5, 8, 11, 13, 14, 16 HSV)
• Electrical
  • Input Voltage: 100V to 240V AC 50/60Hz (Auto Ranging)
  • Current: 145W/0.627A @ 230V/50Hz
• Certifications
  • CE, MET, FCC
  • IP Rating: IP20, Dry Location
• What's in the Box
  • 1x Ovation H-605FC
  • 65°, 45°, 25° Lenses
  • 80° Filter
  • Egg Crate
• Dimensions
  • 333mm x 240mm x 339mm
  • 8.9kg
