The Q8FX is a professional 8-channel analog mixing console, expertly designed and engineered in the UK for musicians, producers, and live sound engineers. It features four ultra-low-noise microphone preamps with dedicated line input options, plus mono inserts on channels 1 and 2 for added flexibility. Additionally, three stereo line input channels provide seamless connectivity for keyboards, synthesizers, drum machines, external media players, and other line-level sources.

Take full control of your mix with a simple yet powerful single-knob compressor on channels 1 and 2, ensuring smooth and dynamic sound. Each channel is equipped with a 3-band EQ and a 75Hz low-cut filter to fine-tune your audio, while the built-in 16-effect DSP engine—offering rich reverbs, delays, and echoes—adds depth and character to any performance.

Ideal for live sound, recording, and production, the Q8FX boasts 2-in/2-out USB functionality for seamless digital integration. Additional features include an auxiliary send with a stereo return, RCA in and out, global phantom power, pan controls on every channel, and an 8-point LED meter for accurate level monitoring. Built into a rugged, portable chassis, the Q8FX is the ultimate solution for musicians, podcasters, and sound engineers who demand performance and reliability.

Features

• High-Quality DSP Effects
• Stereo RCA In/Out
• Stereo Monitor Out
• Stereo Balanced XLR Main Out
• USB Audio I/O
• Comprehensive Monitoring
• Global Phantom Power
• Solid Construction
• Universal ~ 100-240V world-wide operation

Specifications

• Channels: 8
• Mono Inputs (Mic): 4
• Mono Inputs (Line): 2
• Stereo Inputs (Line): 3
• Insert Lines: 2
• Channel EQ: 3 Band
• Compressors: CH1-2 with indicator
• Phantom Power: Global Switch (+48V)
• Main Outs: Stereo balanced XLR sockets
• Phones: Yes (¼" 6.3mm TRS)
• Aux: 1
• FX: 16 Program DSP with Parameter Adjustment
• USB: 2in, 2out
• Master Faders: 60mm Master
• Meters: 8 Point LED
• Frequency Response (Main output): 20-20kHz (+-0.3 dBu)
• THD%: < 0.001% @ 1kHz
• Residual Output Noise: <15uV
• SNR: >110dB
• Channel Crosstalk: > -90dB
• EQ: Treble: 12kHz, +/-15dB, Mid: 2.5kHz, +/-15dB, Bass: 100Hz, +/-15dB
• Input & Output Levels: Mic: +13dBu, Line:+27dBu max, Stereo: >+27dBu, Main Output: +21dBu max, Phones (@
• 150ohms): 300mW
• Input & Output Impedances: Mic: 1.2kΩ, Line Input: 10kΩ, Stereo Input: 21.5kΩ, Outputs: 150Ω (balanced), 75Ω (unbalanced)
• USB Audio: Inputs/Outputs: 2-in, 2-out, 16-bit, 24-bit, Sampling rate: 48kHz (Type B Connector)
• AC Power: Universal 100-240V ~ 50/60Hz (IEC C14 Socket, AC Cord included)
• Power Consumption: 20W
• Product Dimensions (HWD): 96 x 261.5 x 351mm / 3.8" x 10.3" x 13.8"
• Product Weight: 3.3kg / 7.3lbs
