Features

• Stereo direct box for laptops, smartphones, and tablets
• Cable with 3.5mm stereo plug to connect to mobile devices
• Transformer isolation eliminates hum and buzz
• Plug & play easy to use, no power required
• Compact design fits in your laptop bag

Specifications

• Audio circuit type: Passive, transformer based
• Number of channels: Two channels
• Frequency response: 20Hz ~ 20KHz (± 1dB)
• Dynamic range: 100dB
• Total harmonic distortion: 0.01% @ 1kHz
• Phase Deviation: 2° @ 100Hz; 5° @ 50Hz
• Input Impedance: 40k Ohms, unbalanced
• Output Impedance: 2.8k Ohms, balanced
• Maximum Input: +20dB
• Input pad, Mono Sum, Ground lift
• Input Connectors: 3.5mm
• Output Connectors: 1/4" TRS, XLR
• Construction: 14 gauge steel chassis & outer shell
• Size (L x W x D): 4.5" x 1,85" x 1.35" (114mm x 47mm x 34mm)
• Weight: 0.55 lbs (250 grams)
• Shipping size (L x W x D): 8" x 5" x 3" (203mm x 127mm x 76mm)
• Shipping weight: 0.8 lbs (365 grams)
• Power: Passive, no power required
• Conditions: For use in dry locations only between 5°C and 40°C
• Warranty: Radial 3-year, transferable
