RCF ART 912-A 2100W 12 Powered PA Speaker
The combination of a 1.75" compression driver, 12" woofer, two-channel 2100W amplifier, and the constant directivity True Resistive Waveguide produces coherent 100° x 60° coverage for the listening area with up to 130 dB SPL, distortion-free sound.
Used as a stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown, the ART 912-A packs high-performance and reliability in a compact enclosure. Designed to be the most flexible loudspeaker in its class, it also features multiple rigging points for fixed installation.
Merging RCF proprietary FiRPHASE and Bass Motion Control DSP processing, perfectly tuned for each model, the audience will experience absolute clarity and deep, powerful bass response.
The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.
Features
- Up to 130 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 50-20000 Hz linear frequency response
- 1.75" Compression Driver
- 12" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
Specifications
- FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
- MAX SPL @ 1M: 130 dB
- HORIZONTAL COVERAGE ANGLE: 100°
- VERTICAL COVERAGE ANGLE: 60°
- COMPRESSION DRIVER: 1 x 1.0'', 1.75'' v.c
- WOOFER: 12'', 2.5'' v.c
- INPUT SIGNAL: bal/unbal
- INPUT CONNECTORS: XLR, Jack
- OUTPUT CONNECTORS: XLR
- INPUT SENSITIVITY: -2 dBu/+4 dBu
- CROSSOVER FREQUENCIES: 1800 Hz
- PROTECTIONS: Thermal, RMS
- LIMITER: Soft Limiter
- CONTROLS: Linear, Boost, Stage, Volume
- TOTAL POWER: 2100 W Peak
- HIGH FREQUENCIES: 700 W Peak
- LOW FREQUENCIES: 1400 W Peak
- COOLING: Convection
- CONNECTIONS: VDE
- CE MARKING: Yes
- CABINET/CASE MATERIAL: PP Composite
- HARDWARE: 1 x M10 Top, 1 x M10 each side
- HANDLES: 1 Top , 1 each side
- POLE MOUNT/CAP: Yes
- GRILLE: Steel
- COLOR: Black
- HEIGHT: 642 mm / 25.28 inches
- WIDTH: 370 mm / 14.57 inches
- DEPTH: 363 mm / 14.29 inches
- WEIGHT: 19 kg / 41.89 lbs
Watch: RCF ART 9 Series
