Remarkably thoughtful acoustic design coupled with the highest quality drivers and a powerful amplifier make the TT22-A II system the perfect solution for live sound, playback and monitoring.

The amp section has 1100W of power - 800W for bass and 300W for treble. The enclosure is made of marine Baltic birch plywood with a high-strength polyurea finish. The box has two side handles, 6 track type hang points, and receptacles for quick locking pin and metal mast.

---

Features

• 1100W Class D Amplifier
• Constant directivity with 90 ° x60 ° coverage angle
• 12 "woofer, neo, 3.5" voice coil
• C engine. 1.5 ", neo, 3.0" coil
• DSP processing
• Integrated RDNet control
• Multi-function enclosure
• Very high sound pressure

---

Specifications

• FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
• MAX SPL @ 1M: 131 dB
• HORIZONTAL COVERAGE ANGLE: 90°
• VERTICAL COVERAGE ANGLE: 60°
• COMPRESSION DRIVER: 1 x 1.5 '''' neo, 3.0 '''' vc
• BASS SPEAKER: 12 '''' neo, 3.5 '''' vc
• INPUT SIGNAL: bal/unbal
• INPUT CONNECTORS: XLR, RDNet Ethercon
• OUTPUT CONNECTORS: XLR, RDNet Ethercon
• INPUT SENSITIVITY: -2 dBu / + 4 dBu
• CROSSOVER FREQUENCIES: 800 Hz
• PROTECTIONS: Thermal, HF
• LIMITER: Fast Limiter
• CONTROLS: process., 8 sel. presets
• RDNET: And it is
• TOTAL POWER: 2200 W Peak, 1100 W RMS
• TREBLE: 600 W Peak, 300 W RMS
• LOW FREQUENCIES: 1600 W Peak, 800 W RMS
• COOLING: Convection
• CONNECTIONS: Powercon IN / OUT
• CE MARKING: And it it
• CABINET/CASE MATERIAL: Baltic birch plywood
• PHYSICAL EQUIPMENT: 6 x fly tracks, quick lock, pole mount
• HANDLES: 2 Side
• RACK: Steel
• COLOR: Black
• HEIGHT: 600 mm / 23.62 inches
• OVERALL WIDTH: 365 mm / 14.37 inches
• DEPTH OF PACKAGE: 379 mm / 14.92 inches
• PACKAGE WEIGHT: 22.6 kg / 49.82 lbs
