Features

• Unmatched playability with Roland's own PHA-4 keyboard
• Built-to-last with wood and premium materials for years of dependable performance
• Eight RGB-lit assignable knobs, eight RGB-lit pads, and three pedal inputs
• Three customizable zones, onboard arpeggiator, and chord memory
• Thin design with shallow depth fits today's studio environments
• Control application for deep customization and instant recall
• USB-C connectivity and bus power
• MIDI 2.0 ready

---

Specifications

• Controllers:

  • Pad x 8 (with illumination, assignable)
  • Knobs x 8 (with illumination, assignable)
  • Pitch Bend/Modulation lever
  • Button x2 (Assignable)
  • Pedals: DAMPER, FC1, FC2
• Connectors:

  • Pedal (DAMPER, FC1, FC2) jacks: TRS phone type
  • MIDI (IN, OUT) connectors
  • USB (COMPUTER) port: USB Type-C (TM)
  • DC In jack
• Interface: USB 2.0
• Zone: 3 (Lower / Upper1 / Upper2)
• User memory: 8
• Power Supply: Supplied from the computer via USB COMPUTER port / AC-Adaptor
• Current Draw:

  • 260 mA (USB)
  • 300 mA (AC adaptor)
• Accessories:

  • Owner’s manual
  • USB Type-C to USB Type-C cable
  • USB Type-C to USB Type-A cable
• Options:

  • Keyboard stand: KS-12, KS-10Z
  • Piano pedal: RPU-3
  • Damper pedal: DP-10
  • Pedal switch: DP-2
  • Expression pedal: EV-5
  • AC-Adaptor: PSB-1U
• Width: 1,429 mm; 56-5/16 inches
• Depth: 274 mm; 10-13/16 inches
• Height: 119 mm; 4-11/16 inches
• Weight: 16.3 kg; 35 lbs. 15 oz.

---

WATCH: Roland A-88MKII MIDI Keyboard Controller
