The Sennheiser AC 41 is an active antenna combiner to suit evolution wireless G4 systems, and is capable of operating up to four ew series wireless stereo transmitters using a single shared antenna. This combiner supplies the SR IEM G4 transmitters using the BNC cables via NT 3-1 power supply (included), so you don't need to worry about separate power supplies for each transmitter ever again.

Features

• Up to 4 wireless stereo transmitters using one antenna
• Power supply via BNC cables ensures efficient powering, no need for additional power supply units for the SR IEM G4
• Compatible with G4 and G3 systems

Specifications

• Frequency Range
  • 470 - 608MHz
  • 470 - 870MHz
• Impedance: 50Ω
• Power Consumption: max. 3.4A (with Connected Transmitters)
• RF Input: max. 30mW per Input
• Transmission Loss: 0dB (±1 dB)
• Power supply
  • 13.8VDC (with Tabletop Power Supply Unit NT 3-1)
  • 11.4VDC (Protected Against Reverse Supply), 350mA
• What's in the Box?
  • 1x Active antenna splitter (470-870 MHz EU & UK / 470 - 608 MHz US)
  • 1x NT 3-1 power supply with either EU, UK, US adapters
  • 4x BNC interconnect cables
• Dimensions
  • approx. 212mm x 168mm x 43 mm
  • approx. 1.47kg
