More than 30 years’ experience in exclusive keybeds meets an all-new, powerful, operating system. Perfect for you to control your hardware and virtual instruments. All provided in a powerful new refreshing way. Working together with musicians we have created a user interface which is perfect for quick navigation and setup, but also gives you excellent in-depth control. The SL is ready to be at the very heart of your system.

The SL73 Studio adopts the latest hammer action keybed technology from FATAR giving the best piano touch feeling. TP/100LR is remarkably lighter than any other. Each of the keys provides 3 contacts for superior performance. With the respect of the full weighted touch of the real piano action, the new design guarantees a very fluent and authentic feel. The results of this combination are simply amazing.

With its compact profile, the SL is an extremely portable professional controller. Thanks to a perfect integration with the keyboard, it weighs less than 12 Kg for the 73 version. The SL is studio and stage ready with a rugged full metal casing. Sculptured endcaps made of a highly resistant synthetic material help to shield the premium keybed perfectly and provide a safe grip when handling and transporting.

---

Features

• 73 TP/100LR Premium Hammer Action
• Triple switch detection system
• Aftertouch
• 6 Editable user velocity curves (with SL Editor)
• 250 Programs
• 12 Programs Groups and 4 programmable Zones
• 2 MIDI Ports separately assignable
• 3 Programmable sticks
• Rotating encoder with navigation controls
• 3 Function buttons
• Colour graphic LCD - TFT
• Pedal connections: 2 switch, 1 continuous, 1 universal
• MIDI: In, Out1, Out2
• USB: USB to Host, MIDI, USB Powered
• 9V DC IN power supply

---

Specifications

Keyboard

• SL73 Studio: 73 Keys, TP/100LR Premium Hammer Action
• Triple switch detection system
• Aftertouch
• Touch: Soft, Medium, Hard, Fixed (programmable)
• 6 Editable user velocity curves (with SL Editor)

Controls / UI

• 3 Programmable sticks
• Rotating encoder with navigation controls
• 3 Function buttons
• Display

  • Color graphic LCD - TFT
  • 320 x 240

Connections

• Pedals: 2 switch, 1 continuous, 1 universal
• MIDI: In, Out1, Out2
• USB: USB to Host, MIDI, USB Powered

Power supply

• DC IN: 9V
• Adapter: Input: 100-240V / Output: 9V-1A

Size and weight

• Width: 104 cm / 41"
• Depth: 31 cm / 12,2"
• Height: 12,5 cm / 4,9"
• Weight: 11,5 Kg / 25,3 lbs

Package content

• SL73 Studio
• Studiologic PS100 switch pedal
• Power adapter
