Features

• 18” subwoofer with 4” Voice Coil
• High power 1000W (PGM) input
• Cardioid mode capable with processors or DSP onboard power amps
• Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
• SpeakON NL4MP x 3 (Parallel x2, Output x1)
• Dual-pole socket
• Optional speaker cover (SPCVR-DXS18X) and wheel kit (SPW-1)
• Durable Black finish

---

Specifications

• Speaker type: Subwoofer, Bass-reflex
  Frequency range (-10dB): Passive: 32 Hz - 3kHz, Normal (*1): 32 Hz - 150 Hz, Extend (*1): 29 Hz - 150 Hz
• Coverage area: -
• Floor Monitor Angle: -
• Components LF: 18" Cone, 4" Voice Coil, Ferrite magnet
• Components HF: -
• Crossover: -
• Power Rating NOISE: 500 W (EIA 426-A)
• Power Rating PGM: 1000 W (EIA 426-A)
• Power Rating PEAK: 2000 W (EIA 426-A)
• Nominal impedance: 8Ω
• SPL Sensitivity (1W; 1m on axis): 100dB *2
• SPL Peak (Calculated): 133 dB *2
• I/O connectors: SpeakON NL4MP x 3 (Parallel x2, Output x1)
• Handle: Aluminium die-cast, Side x2
• Pole socket: Φ35 mm (depth 80mm), M20 Threaded (depth 25mm)
• Rigging: -
• Width: 550 mm (21.6")
• Height: 657 mm (25.9") (with rubber feet)
• Depth: 720 mm (28.4")
• Net weight: 43.6kg (96.1 lbs)
• Options: Cover: SPCVR-DXS18X, Caster: SPW-1
• Others: Enclosure Material, Finish, Color: Plywood, Durable Polyurea coating, Black/White

---
