More than three decades after Yamaha introduced its first digital mixer, the DMP7, the world of professional audio has undergone remarkable technological evolution, reshaping how mixing and recording are approached.

The DM7 series marks a significant leap forward in this ongoing progression—blending innovative design, intuitive user interfaces, and a powerful feature set into a compact, versatile package. Engineered to excel across a wide spectrum of audio applications—from broadcasting, streaming, and music production to live hybrid events and concert performances—the DM7 delivers unmatched operability and streamlined workflows.

True to Yamaha’s legacy of natural, pristine sound, the DM7 series raises the bar for sonic excellence while offering an elevated user experience that keeps you ahead in an ever-changing industry. Whether on stage or in the studio, the DM7 stands out as a benchmark for performance, flexibility, and intuitive control, exceeding the demands of both audio professionals and discerning audiences alike.

Features

• Off to a solid start
  Powerful Channel Strip
  Extensive plug-ins and new effects
  Advanced GUI for intuitive control
  Configure the ideal DM7 system to suit your workflow
  Utility screen for streamlined performance
  Advanced Selected Channel View and visible Overview

Specifications

• Channels: 120
• Inputs - Mic Preamps: 32 x XLR
• Phantom Power: 32 Channels
• Outputs - Main: 16 x XLR (main)
• Inputs - Digital: 2 x XLR (AES/EBU), 2 x RJ-45 (Dante)
• Outputs - Digital: 2 x XLR (AES/EBU)
• Busses/Groups: 48 mixes, 12 matrixes, 2 stereo buses, and 2 cue mixes
• MIDI I/O: 1 x 15-pin DIN (GPI)
• Data I/O: 2 x Locking Ethernet (Dante network), 1 x RJ-45 (control)
• Headphones: 1 x 1/4"
• USB: 1 x Type C
• Computer Connectivity: USB (18 x 18), Ethernet
• I/O Expansion Slots: 1 x Slots Available
• Word Clock: 2 x BNC (in/out)
• Faders: 28 x Motorized
• A/D Resolution: Up to 24-bit/96kHz
• Effects: Yes
• Signal Processing: 64 Assignable Processing Slots, 16 Assignable FX Slots, 4 x Inserts per Channel
• Features: A.I. Mix Assistant
• Transport Controls: Yes
• DAW Control: Yes
• Screen: 2 x 12" touchscreen, 7" touchscreen
• Software: DM7 Editor, DM7 StageMix, Console File Converter, MonitorMix, ProVisionaire Control/Touch
• Power Source: 2 x Standard IEC AC Cable (redundant power supply)
