Perfect for live sound reinforcement and fixed installations. The HDL 20-A is the ideal choice for when a line array is required with quick and easy commissioning.

The system uses a two-way digital amplifier with 1400W peak power, complemented by a powerful digital signal processor, which includes corrections for treble projection and presets for indoor or configurations with a lot of curvature.

The system makes use of high-tech RCF drivers, two powerful 10 ”drivers for solid bass, and a 3” coil compression driver for high definition and vocal clarity with incredible dynamics.

---

Features

• 1400 W PEAK, 700 W RMS
• 135 dB SPL max
• 55 Hz to 20 kHz frequency response
• 2 x 10 "woofers
• 1 3 "compression driver
• Input section with DSP control and selectable memories
• Suitable for touring use, solid anchors for hanging
• PP composite enclosure with wood structural reinforcements

---

Specifications

• FREQUENCY RESPONSE: 55 Hz ÷ 20000 Hz
• MAX SPL @ 1M: 135 dB
• HORIZONTAL COVERAGE ANGLE: 100°
• VERTICAL COVERAGE ANGLE: 15°
• COMPRESSION DRIVER: 1 x 2.0'''', 3.0'''' vc
• BASS SPEAKER: 2 x 10'''', 2.5'''' vc
• INPUT SIGNAL: bal/unbal
• INPUT CONNECTORS: XLR
• OUTPUT CONNECTORS: XLR
• INPUT SENSITIVITY: -2 dBu/+4 dBu
• CROSSOVER FREQUENCIES: 800 Hz
• PROTECTIONS: Thermal, RMS
• LIMITER: Soft Limiter
• CONTROLS: Cluster, HF, High curving, Indoor
• TOTAL POWER: 1400 W Peak, 700 W RMS
• TREBLE: 400 W Peak, 200 W RMS
• LOW FREQUENCIES: 1000 W Peak, 500 W RMS
• COOLING: Convection
• CONNECTIONS: Powercon IN / OUT
• CE MARKING: And it it
• CABINET/CASE MATERIAL: PP Composite
• PHYSICAL EQUIPMENT: Rigging flyware
• HANDLES: 2 Side, 2 back
• RACK: Steel
• COLOR: Black
• HEIGHT: 294 mm / 11.57 inches
• OVERALL WIDTH: 705 mm / 27.76 inches
• DEPTH OF PACKAGE: 445 mm / 17.52 inches
• PACKAGE WEIGHT: 30.2 kg / 66.58 lbs
