Features

• 650 high quality Voices, 260 auto accompaniment Styles
• Touch-sensitive keyboard with 48-note polyphony
• 125 onboard Songs, easy Song Book (available via web download)
• 12 Super Articulation Lite Voices
• Reverb, Chorus and 41 types of DSP effects
• 26 Harmony types
• 152 Arpeggio types
• Brand new "Auto Chord Play" function for Style
• "Keys to Success" with various lesson functions
• Duo mode
• USB Audio/MIDI Recording/Interface
• Battery operation (AAx6)

Specifications

Control Interface

• Keyboard Number of Keys: 76 Type: Organ-style Touch Response: Yes (Soft, Medium, Hard, Off)
• Display Type: LCD Backlight: Yes Language: English
• Panel Language: English

Voices

• Tone Generation Tone Generating Technology: AWM Stereo Sampling
• Polyphony Number of Polyphony (Max.): 48
• Preset Number of Voices: 650 (258 Panel Voices + 25 Drum/SFX kits + 20 Arpeggio + 347 XGlite Voices)
• Compatibility GMX: Yes Glite: Yes

Effects

• Types DSP: 41 types Reverb: 15 types Chorus: 7 types Master EQ: 5 types Harmony: 26 types
• Functions Dual: Yes Split: Yes Arpeggio: 152 types Melody Suppressor: Yes

Accompaniment Styles

• Preset Number of Preset Styles: 260 Fingering: Smart Chord, Multi finger Style Control: ACMP ON/OFF, SYNC START, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL File Format: Style File Format (SFF)
• Other Features Music Database: 200 One Touch Setting (OTS): Yes Auto Chord Play: 50 Chord Progressions
• Expandability Expansion Style: 10

Songs

• Preset Number of Preset Songs: 125
• Recording Number of Songs: 5 Number of Tracks: 2 Data Capacity: Approx. 10,000 notes
• Compatible Data Format Playback: SMF Formats 0 & 1 Recording: Original File Format

Functions

• Lesson: KEYS TO SUCCESS, 3-Step Lesson (Listening, Timing, Waiting), A-B Repeat, Rhythm & Touch Tutor
• USB Audio Interface: 44.1 kHz, 16 bit, stereo
• Registration Number of Memories: 10
• Overall Controls Metronome: Yes Tempo Range: 11 - 280 Transpose: -12 to 0, 0 to +12 Tuning: 427.0–440.0–453.0 Hz (approx. 0.2 Hz increments) Duo: Yes
• Miscellaneous PIANO Button: Yes (Portable Grand Button)

Storage and Connectivity

• Storage Internal Memory: Approx. 1.4 MB
• Connectivity DC IN: 12V Headphones: Standard stereo phone jack (PHONES/OUTPUT) Sustain Pedal: Yes AUX IN: Yes (Stereo mini jack) USB TO HOST: Yes (MIDI/AUDIO)

Amplifiers and Speakers

• Amplifiers: 2.5 W + 2.5 W
• Speakers: 12 cm × 2

Power Supply

• Power Supply Adaptors: PA-130 or an equivalent recommended by Yamaha Batteries: Six “AA” size alkaline (LR6), manganese (R6), or Ni-MH rechargeable batteries (HR6)
• Power Consumption: 5 W (When using PA-130 AC adaptor)
• Auto Power Off: Yes
• Accessories Included Accessories Music Rest: Yes Song Book: Download from Yamaha web site
