The PSR-EW400 series is an excellent gigging instrument, with a 76-key keyboard that more experienced players can make the most of. The latest PSR-EW425 features a newly developed tone generator that delivers stunning improvements in sound quality as well as high-quality effects such as delays, and as a premium organ sound sampled from the YC series of high-end stage keyboards.

---

Features

• 820 Voices and Super Articulation Lite Voices
• Premium organ sound
• 290 Styles
• 2 channels/41 types of DSP insertion effects
• Quick Sampling
• Groove Creator
• Live Control Knobs, Motion Effect functionality, pitch bend wheel
• Mega Boost
• Direct Category Access buttons
• USB Audio Recording/Interface
• Mic input and vocal effects
• Individual L/R outputs
• 12W + 12W powerful speakers

---

Specifications

• Body Color: Black
• Width: 1,200 mm (47-1/4”)
• Height: 136 mm (5-3/8”)
• Depth: 404 mm (15-7/8”)
• Weight: 8.3 kg (18 lb, 5 oz) (not including batteries)
• Number of Keys: 76
• Touch Response: Yes (Soft, Medium, Hard, Fixed)
• Type: Organ-style
• Pitch Bend: Yes
• Art. Switches: Yes
• Control Knobs: 2
• Display Type: LCD
• Backlight: Yes
• Panel Language: English
• Tone Generating Technology: AWM Stereo Sampling
• Number of Polyphony (Max.): 64
• Number of Voices: 820 (294 Panel Voices + 28 Drum/SFX kits + 40 Arpeggio + 458 XGlite Voices)
• Featured Voices: 10 Premium Organ Voices, 4 Live! Voices, 9 Sweet! Voices, 6 Cool! Voices, 14 Super Articulation Lite Voices
• Compatibility GM: Yes
• Compatibility XGlite: Yes
• DSP: DSP1: 41 types, DSP2: 12 types
• Reverb: 12 types
• Chorus: 5 types
• Master EQ: 4 types
• Dual/Layers: Yes
• Split: Yes
• Melody Suppressor: Yes (w/ pan adjustment)
• Crossfade: Yes (between Internal Sound and External Audio)
• Internal Memory: Approx. 1.72 MB
• External Drives: USB flash drive
• DC IN: 16 V
• AUX IN: Stereo mini jack x 1
• Headphones: Standard stereo phone jack x 1
• Sustain Pedal: Yes
• USB TO DEVICE: Yes
• USB TO HOST: Yes
• OUTPUT: Standard phone jack x 2
• Microphone: Standard phone jack x 1
• Amplifiers: 12 W + 12 W
• Speakers: 12 cm x 2
• Power Supply: AC Adaptors (PA-300C or an equivalent recommended by Yamaha) or batteries (Six “D” size alkaline (LR20), manganese (R20) or Ni-MH rechargeable (HR20) batteries)
• Power Consumption: 11 W (When using PA-300C AC adaptor)
• Auto Power Off Function: Off/5/10/15/30/60/120 (minutes)
• Music Rest: Yes
• Song Book: Download from Yamaha web site

---

Watch: Yamaha Portable Keyboard PSR-EW425
