With a smooth uniform frequency response from 40 Hz – 20 kHz, the SCX1 is very consistent when responding to on and off-axis signals, and exhibits excellent phase coherence and minimal proximity effect. The SCX1 is characterized by a wide cardioid polar pattern; this, coupled with the high output and sensitivity of the microphone, makes the SCX1 an ideal choice for miking overhead, drums, instruments, room ambiance, orchestral sections, stringed instruments, piano, vibes, and sound effects. The SCX1HC condenser microphone is a number one choice for miking hi-hat both live and in the studio. Other features include a 21 mm gold vapor capsule, miniaturized electronics, and an extremely small footprint. The SCX1 will handle sound pressure levels of 130 dB and will provide up to 20 dB of ambient noise rejection. In addition to acoustic instruments, the SCX1 is an excellent choice for group vocals, speech, or Foley work. The SCX1HC has become a popular choice for interior dialogue boom pole miking. It has a precision machined brass body, interchangeable capsules, black multi-layer class ‘A’ liquid finish, and a gold-plated XLR connector. The SCX1 studio condenser microphone is manufactured to exacting standards and tight tolerances. Designed, machined, assembled, and tested by Audix in Wilsonville, Oregon Applications

• Studio vocals, group vocals
• Speech
• Overheads, hi-hat
• Orchestra, symphony
• Acoustic stringed instruments
• Piano, vibes, flute, bells, chimes, marimba
• Audience mics for in-ear monitors

Features

• Professional, studio quality cardioid condenser
• Extremely sensitive with pin-point accuracy
• 21 mm gold vapor capsule with modular design

Specifications

• Transducer Type Condenser
• Frequency Response 40Hz - 20 kHz
• Polar Pattern Cardioid / Hypercardioid / Omni
• Output Impedance 200 ohms
• Sensitivity 26 (C) | 17 (HC) | 15 (O) mV / Pa @ 1 kHz
• Maximum SPL 130 dB
• Equivalent Noise Level >14 dB (a-weighted)
• Signal to Noise Ratio 80 dB
• Polarity
  • Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output
  • XLR connector
• Power Requirements 48-52V Phantom
• Connector 3-pin XLRm
• Materials / Finish Machined Brass / Black
• ProductWeight 114 g / 4 oz
